Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Specifications
Brand Name :
YJFIRST
Model Number :
YJ-ES531
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
$81
Payment Terms :
T/T
Supply Ability :
20000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
Gift box
Product name :
Passport Document Reader
Symbologies :
1D/2D/QR Code
Application :
Kiosk,Vending Machine
Light source :
LED Lights
Weight :
<35g
Successful Prompt :
Green LED, Beeper
Description

Passport Document Reader International Travel Passport Reader Passport Ocr Scanner

product features

Compact Form - factor: The scanner has a small, square - shaped body, which is highly space - efficient and

portable.

USB Connectivity: It is equipped with a standard USB cable, allowing for easy and quick connection to different

devices, such as computers and tablets.

Fast Scanning: Capable of rapidly reading barcodes, it significantly improves the speed of data - collection tasks.

High Accuracy: Offers precise barcode recognition, minimizing errors in data entry and collection.

Indicator Lights: Features indicator lights on the front, which provide visual feedback on the scanning status and

device operation.

Product Description

Sensor Capability

Image Sensor

1280*800 CMOS

Acquisition speed

60fps

Field of View

Diagonal 48.7°,Horizontal 42°,Vertical 27°

Scan Capability

Scan Precision

2D≥4mil,1D≥3mil

Depth of Field

Testing Condition

Code 39 (4mil)

60~160mm

Code 128 (5mil)

40~230mm

Code 39 (5mil)

45~200mm

Code 39 (20mil)

70~420mm

100% UPCA

55~310mm

PDF417 (5mil)

40~220mm

Data Matrix (10mil)

35-210mm

QR Code (20mil)

35~340mm

Scan Angle

Roll 360°,Pitch ± 55°,Skew ± 55°

Symbologies

2D Code: QR Code,Data Matrix,PDF417,Hanxin Code,Dotcode etc

1D Code: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128,

ISBT 128, Code 39, Code93,Code 11, Interleaved 2 of 5, Industrial 2 of 5,Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar etc

OCR-A,OCR-B(*Customized Version)

Minimal Print Contrast

20%

LED

Illumination

White LED

Laser Aiming

Aiming

Laser diode 650nm

Mechanical

Dimension

(W×D×H):41.4mm×48mm×21mm

Weight

35g

Interface

Interface

USB serial port/USB KBW/USB HID-POS/TTL-3.3V/TTL-5V/RS232/RS485

Cable

2 meter USB-A cable,2 meter DB9 cable with USB power supply

Scan Mode

Trigger mode /Command mode /Sense mode

Environmental

Operating Temperature

-30℃ ~ 70℃

Storage Temperature

-40℃ ~ 80℃

Humidity

5% ~ 95%(non-condensing)

Ambient Light

Max.100,000 Lux

Electric

Input Voltage

3-3.6V or 3.6-16V

Current@5VDC Operating

<220mA

Current@5VDC

Standby

<15mA

Certifications

Certificates

IEC62471

Warranty

2 Years
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Company Profile
Compact Passport Document Reader High Accuracy Travel Document Scanner
Shenzhen Yuanjie Information Technology Co., LTD. (YJFIRST) is one of the leading professional barcode scanner
manufacturers in China. YJFIRST specializes in barcode reading technology and has more than 10 years of experience
in the barcode scanning technology industry. YJFIRST's products include 1D and 2D barcode scanners, laser and CCD
barcode scanners, wireless barcode scanners, barcode scanner modules, scanning engines, omnidirectional scanning
platforms, and more. All products have passed CE, FCC, RoHS, IP54, RF certification, has been widely used in logistics,
supermarket, retail, medical, postal communication, office automation, manufacturing and other fields.
We support OEM and ODM orders, welcome to visit our factory in China ! We will provide customers with high quality
products at competitive prices.
Compact Passport Document Reader High Accuracy Travel Document Scanner
Compact Passport Document Reader High Accuracy Travel Document Scanner
Exhibition
Compact Passport Document Reader High Accuracy Travel Document Scanner
Applications
Compact Passport Document Reader High Accuracy Travel Document Scanner
Transportation
Compact Passport Document Reader High Accuracy Travel Document Scanner
FAQ
Q:Can you send sample?
A:Yes, YJFIRST welcomes sample order to test. Please contact us for more details before placing sample order.
Q:Can we have our logo or company name to be printed on the product or package?
A:Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing,please contact us for more
details.
Q:What's the shipping way?
A: There are DHL, Fedex, TNT, UPS. We also can ship the goods by your shipping account or other express agent you provided.
Q:What's the payment way?
A:We accept Alibaba online orders, PayPal ,T T, LC, Westem Union , MoneyGram.
Q:How about your product warranty?
A:Our oficiallyy promised warranty time is two years after delivery.
Q:How is your quality control?
A:Professional QC team and testing machine( Engine age testing, wire bending machine, switch life testing, shock resistance
testing). CE, FCC & ROHS certificated.
Q:If I come across any problem during product using, where I can get the support?
A:We support you technically 24h/7. Please send all your questions to us, and we will give the professional, patient, expliantion
by email or call in time.
