HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
Specifications
Brand Name :
HRB
Model Number :
NN3022K/P4 W33(3282122)
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
T/T or western Union or PayPal
Supply Ability :
3,000pcs per month
Delivery Time :
3 working days after received your payment
Packaging Details :
Packed in carton firstly,and then reinforced with wooden case for outer packing
Structure :
Cylindrical
Type :
Roller
Material :
Chrome steel
Application :
Vibration machinary,CNC machine and so on
Cage :
Brass cage
Description

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing

Bearing name :bearing for CNC machine cylindrical roller bearing

Model : NN3022K/P4 W33

Size : 130*182*52 mm

Weight : 5.88 KG

Material : GCR-15

Precision : P5

Quality : ISO9001:2008 approved

OEM service: Offer

Types of cylindrical roller bearing:

.Single row cylindrical roller bearing: NU, NJ, NUP, NUB series

.Double row cylindrical roller bearings:NNU series

.Four row cylindrical roller bearing:FC series

.Single row full complement cylindrical roller bearing:SL18 series, SL 19 series

.Double row full complement cylindrical roller bearing

.SL01 series, SL02 series, SL18 series.

Bearing type Cage symbol Specification Available size
NN MB Roller guided machined brass cage

NN3005,NN3026-NN3040

NN3920-NN3956,NN4920-NN4940
TB Roller guided PPS resin cage NN3006-NN3024
NNU MB Roller guided machined brass cage NNU4920-NNU4940
N MR Roller guided machined brass cage N1006-N1028
TP Outer ring guided PEEK resin cage N1009-N1017

Import NSK precision spindle Cylindrical roller bearing NN3022K/P4W33 design draft :

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing

Cylindrical roller bearings NN3022K/P4W33

Bearing number : NN3022K/P4W33

Size (mm) : 110x170x45

Brand : NSK

Bore Diameter (mm) : 130

Outer Diameter (mm) : 182

Width (mm) : 52

Bearing dimensions and specification in brand catalogue :

d - 110 mm

D - 170 mm

E - 45 mm

B - 45 mm

C - 45 mm

r min. - 2 mm

Weight - 3.41 Kg

Basic dynamic load rating (C) - 260 kN

Basic static load rating (C0) - 360 kN

(Grease) Lubrication Speed - 6000 r/min

(Oil) Lubrication Speed - 5 500 r/min

Dimension

(mm)

 Weight (kg)

Rated load

( KN)

Limiting speed

(r/min)

 Type
d D B r min F E Cr Cor Grease oil
100 140 40 1.1 113 137 1.88 125 244 4300 5100 NNU4920
150 37 1.5 -- 146 245 4000 4800 NN3020
105 145 40 1.1 118 146 1.96 132 270 4100 4800 NNU4921
160 41 2 -- 2.96 192 310 3800 4100 NN3021
110 150 40 1.1 123 155 2.04 132 258 3900 4600 NNU4922
170 45 2 -- 3.76 226 365 3600 4300 NN3022
120 165 45 1.1 134.5 165 2.76 170 328 3600 4200 NNU4924
200 80 1.112 141 11 -- -- -- -- NNU4124
180 46 2 -- 4.1 232 390 3300 3900 NN3024
130 180 50 1.5 146 182 3.79 187 368 3300 3900 NNU4926
200 52 2 -- 6.04 284 475 3100 3600

NN3026

Bearing photos:

HRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 BearingHRB NN3022K/P4 W33 Double Row Full Complement Cylindrical Roller Bearing 3282122 Bearing
