Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Specifications
Brand Name :
COMESH
Model Number :
AIL250212
Place of Origin :
China
MOQ :
1 meter
Price :
USD2.0~USD8.0
Payment Terms :
T/T
Supply Ability :
100m per month
Delivery Time :
5-8days
Packaging Details :
plywood box
key words :
Wire Mesh Conveyor Belt
production name :
Wire Conveyor Belts
Chain Pitch :
5mm to 15mm
Spiral Pitch :
2.4 Mm To 100 Mm
Pitch Of Spirals :
2.8mm To 40mm.
Surface :
Bright Silver
Width :
0.3 mm to 1.5 mm
Edge Treatment :
Polishing
Applications :
Food Grade
Description
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Product Specifications
Attribute Value
Key Words Wire Mesh Conveyor Belt
Production Name Wire Conveyor Belts
Chain Pitch 5mm to 15mm
Spiral Pitch 2.4 Mm To 100 Mm
Pitch Of Spirals 2.8mm To 40mm
Surface Bright Silver
Width 0.3 mm to 1.5 mm
Edge Treatment Polishing
Applications Food Grade
Product Description

Ladder wire mesh conveyor belt is also known as Z-surface metal mesh belt, rod mesh belt, ladder belt, 45° 90° 180° mesh belt, flat flexible conveyor belt, Enrober conveyor belt. This mesh belt has a large opening, good air permeability, flexible rotation, good stability, suitable for various conveying equipment, ensuring smooth material transmission, and is an ideal metal conveyor belt for light conveying.

The B-shaped mesh belt usually has a single-layer structure, is lighter, and is driven by a sprocket. The pitch, total width, wire diameter, side width, material and length of the mesh belt can be customized according to customer needs.

Technical Specifications
Name Stainless steel conveyor belt
Material SS304 wire, SS 316 wire
Wire diameter 1.5mm 1.8mm 2mm 2.5mm
Span (space) 60mm 65mm 70mm 75mm
Spiral pitch 10mm 13mm 15mm 20mm
Roll wide 20cm 48cm 50cm

We can make it as customer's customized
Detailed Specifications
Item Wire diameter (mm) Pitch (mm) Open area (%) Edge type
FFCB-01 0.9 4.24 77 Single/double
FFCB-02 0.9 5.64 82 Single/double
FFCB-03 1 5.5 79 Single/double
FFCB-04 1 5.6 79.5 Single/double
FFCB-05 1.27 4.3 67 Single
FFCB-06 1.27 5.5 73 Single/double
FFCB-07 1.27 6 76 Single/double
FFCB-08 1.27 6.35 77 Single/double
FFCB-09 1.27 7.26 80 Single/double/C-shape
FFCB-10 1.4 6.4 76 Single/C-shape
FFCB-11 1.6 7.26 75 Single/double/C-shape
FFCB-12 1.83 12 81 Single
FFCB-13 1.83 12.7 82 Single/C-shape
FFCB-14 2.08 9.6 75 Single/C-shape
FFCB-15 2.35 12.7 78 Single/C-shape
FFCB-16 2.35 20.32 85 Single
FFCB-17 2.8 12.7 72 Single/C-shape
Custom specification is available if you can't find the suitable size.
Ladder Mesh Conveyor Belt For Cooking Transporting Baking And Heating
Product Advantages
  • Permeability - stainless steel mesh belt, ventilation rate, reduce permeability of heat cost and improve the efficiency of drying.
  • Fire retardant - stainless steel mesh belt is not burning, fire prevention.
  • Chemical corrosion resistance to acid, alkali, corrosion of various kinds of organic solvents.
  • Good dimensional stability (elongation coefficient is less than 5 ‰), the intensity is high. With good mechanical properties.
  • Stainless steel mesh belt bending fatigue resistance and can be used for small wheel diameter.
  • resistance, non-toxic. Resistant to almost all items.
Applications

Widely used in many automatic glass work; petro chemistry fiber; food industry; glass fiber; electric furnace; kiln furnace; machinery; power metallurgy; purging; reflux welding; metal heat treatment and stoving furnace etc.
