IPX8 Waterproof Pressure Environmental Test Chamber for Deep Water Immersion and Sealing Integrity Testing
IPX8 Waterproof Pressure Environmental Test Chamber for Deep Water Immersion and Sealing Integrity Testing
Specifications
Brand Name :
HeJin
Model Number :
HJ-EMTC-006
Certification :
Calibration Certificate(Cost Additional)
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiatable
Payment Terms :
L/C,T/T
Supply Ability :
10 Set per month
Delivery Time :
60 working days
Packaging Details :
Plywood
Material :
SUS304#
Voltage :
AC220V 50Hz
Pressure Accuracy :
±1% FS
Sealing Type :
Multi-layer pressure sealing
Test Standard :
IEC 60529 IPX8
Warranty :
One year for quality issues not caused by human error
Description
IPX8 Waterproof Pressure Environmental Test Chamber for Deep Water Immersion and Sealing Integrity Testing
Product Introduction

The Hejin IPX8 pressure testing chamber is designed to simulate continuous immersion under specific water pressure, verifying the integrity of seals, structural reliability, and long-term waterproof performance. Unlike ordinary immersion tanks, this environmental testing chamber applies controlled pressure to simulate real underwater environments—suitable for everything from consumer electronics to automotive and industrial components.

Every detail of this testing chamber reflects Hejin's manufacturing philosophy: precision, stability, and practicality. The pressure system responds smoothly, the chamber structure remains rigid under load, and test data exhibits excellent repeatability—even during prolonged IPX8 testing.

As a direct manufacturer, Hejin focuses on solving the real-world testing challenges faced by customers worldwide, ensuring your products successfully pass certification, audits, and real-world usage tests.

International Reference Standards
  • IEC 60529 – Degrees of Protection (IP Codes)

    IPX8: Persistent immersion in water under manufacturer-specified conditions

  • GB/T 4208

    Degrees of Protection Provided by Enclosures (IP Codes)

  • IEC 60068-2-18

    Environmental Testing – Test R: Water Immersion Test Method

Applications & Typical Uses
  • Waterproof performance verification
  • Product sealing integrity testing
  • Deep water immersion simulation
  • Pre-certification IPX8 testing
  • Quality control and R&D validation
Technical Parameters
Test Items Specific Parameters
Pressure Adjustment MethodAutomatic Control
Control Accuracy±0.002Mpa (Automatic)
Pressure Adjustment Range0~1.0Mpa
Test Water Depth Range0~100 meters
Maximum Ultimate Pressure1.1Mpa
External Dimensions460*580*920mm
MaterialSUS304#
Tank Thickness6mm
VoltageAC220V 50Hz
Power100W
Weight100kg
FAQ
Q1: What is the difference between IPX7 and IPX8 testing?

IPX8 requires continuous immersion under specified pressure conditions, while IPX7 is limited to shallow, time-defined immersion.

Q2: Can pressure and test time be customized?

Yes. Both parameters are fully adjustable based on product requirements.

Q3: Is this chamber suitable for certification testing?

It is widely used for pre-certification and internal verification testing.

Q4: Can large or irregular products be tested?

Custom chamber sizes and fixtures are available.

Q5: Is training required to operate the machine?

Operation is straightforward, and guidance is provided.

Detailed images:

IPX8 Waterproof Pressure Environmental Test Chamber for Deep Water Immersion and Sealing Integrity Testing
