High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
Specifications
Brand Name :
XINGTE
Model Number :
XT-606HX001
Certification :
CE / IOS 9001
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
2.000 sets per year
Delivery Time :
30-40 working days
Packaging Details :
Wooden case
Application :
Various speaker coil winding And Diaphragm Assembly
Weight :
650KGS
Dimensions :
1630*1200*1800mm
After-sales service provided :
engineers available to service machinery overseas, Online Video technical support
Voltage :
220v 50/60HZ
Name :
Automatic Voice Coil Winding And Diaphragm Wire Arranging machine
Warranty :
12 Monthes
Function :
speaker Voice Coil Winding And Diaphragm Wire Arranging
speed :
1500pcs/H
Description
High Efficiency Fully Automatic Voice Coil Winding Machine 6KW XT-606HX001
This fully automatic voice coil winding and diaphragm wire arranging integrated machine glues voice coil lead wires and sound diaphragms of speakers together in a specific shape.
Product Features
  • Uses natural drying method with conventional glue instead of UV glue and UV lamps, significantly reducing speaker auxiliary material costs
  • Automatic lead wire arrangement, precise glue dispensing, beautiful arc appearance, and excellent consistency
  • Lead wire arrangement arc exceeds 140 degrees, with complete matching between copper wire and high/low arc surfaces of sound diaphragm, extending speaker life in noise testing
  • Small, precise glue dispensing amount improves speaker frequency response curve consistency and sensitivity
  • Rotary type 12 stations with minimal fixture count and high interchangeability between large and small fixtures, reducing fixture replacement costs
  • Fully automatic loading and unloading with no manual intervention; production capacity of 1600pcs/h*24 hours
Application Areas
  • Headphone voice diaphragm
  • In-ear headphone voice diaphragm
  • True wireless Bluetooth headset voice diaphragm
  • Security speaker voice diaphragm
  • Receiver and other voice diaphragm and voice coil combinations
Product Parameters
Model number XT-606HX001
Wire Diameter 0.02-0.15mm (can be customized)
Coil stack height ≤20mm
Coil outer diameter ≤20mm (can be customized)
Yield rate > 98%
Utilization rate >85%
Capacity 1500pcs/H
Diaphragm diameter 6-48mm
Diaphragm height >0.006mm
Power 6KW
Power supply AC 220V, 50/60Hz
Air pressure > 0.6Mpa
Machine dimension 1630*1200*1800mm
G.W. 650KGS
About XINGTE
Experience: Established in 2007, with more than 17 years R&D experience in coil winding
Plant Size: Headquarters in Shenzhen with factory area over 30,000 square meters ensuring strong productivity
Service: Over 230 technical service and after-sales staff with worldwide service points
Patents & Certificates: 120+ patents and related certificates obtained
Production Capacity: Over 600 experienced employees ensuring production capacity and fast delivery
Technology: Over 130 experienced engineers ensuring strong R&D and customization capabilities
XINGTE Production Line
  1. Motor stator, rotor and other related coil winding machines
  2. Transformer-related product coil winding machines
  3. Voice coil-related product winding machines
  4. Inductor coil winding machines
  5. Customized fully automatic lines for motor, speaker, and transformer production lines
