Joytech AC Motor PY1800AC Automatic Gate Opener For 1800kg Sliding Gate With 600w Rated Power
Joytech AC Motor PY1800AC Automatic Gate Opener For 1800kg Sliding Gate With 600w Rated Power
Joytech AC Motor PY1800AC Automatic Gate Opener For 1800kg Sliding Gate With 600w Rated Power
Joytech AC Motor PY1800AC Automatic Gate Opener For 1800kg Sliding Gate With 600w Rated Power
Specifications
Brand Name :
SINOMATIC
Model Number :
PY1800AC
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T, Western Union, , credit card/Cash/Alipay, L/C, D/A, D/P
Supply Ability :
10,000 pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Packing Material :
Carton
Remote Control Code :
Rolling code
Gear Modulus :
M=4
Design Style :
Modern
Ip Level :
IP54
Remote Control Mode :
Single button mode / Three button mode
Work Duty :
S2 15min
Quality Durability :
One million lifespan
Manual Release :
Yes
Max Gate Weight :
1800kg
Weight :
16KG
Safety Features :
Infrared Sensor, Auto Stop/Reverse
Remote Control :
Included
Description
PY1800AC Automatic Gate Opener for 1800kg Sliding Gates
The PY series gate opener is engineered for commercial and industrial applications, capable of handling gates weighing up to 1800kg with operating distances up to 12 meters.
Product Overview
  • Heavy-duty construction with oil lubrication system
  • Compact, cost-effective design
  • Built-in control board or separate control box options
  • Keypad and single button interface
  • Alarm lamp, photo beam & safety beam interfaces
  • Auto-close function selection
  • Optional spring or magnetic limit switches
  • Emergency manual key release mechanism
  • Smart version features obstacle detection and auto-reverse functions
  • Complete installation accessories included
Technical Specifications
Model PY1800AC
Power Supply 220V/50Hz; 110V/60Hz
Max. Gate Weight 1800KG
Motor Power 600W
Gate Moving Speed 11-13 m/min
Limit Switch Spring (mechanical) / magnetic
Remote Control Capacity 20 pcs / 44 pcs
Decoding / Frequency Rolling code / 433.92MHz
Work Duty S2 20min
Noise Level ≤58dB
Operating Temperature -20°C~70°C
Key Features
  • AC motor with integrated control unit
  • Keypad and single button interface options
  • Alarm lamp, photo beam and safety beam interfaces
  • Configurable auto-close function
  • Smart version includes soft start and slow stop
  • Auto-reverse function when encountering obstacles during closing
  • Emergency manual key release system
Standard Package Contents
  • Gate Motor
  • Control board & box
  • 2 remote controls
  • Manual release key
  • User manual
  • Bolts & nuts
Optional Accessories
  • Metal Gear Rack & Nylon Gear Rack (custom lengths available)
  • Photo beam sensor
  • Keypad systems
  • Push button
  • Warning light
  • Solar panel
  • Backup batteries
Manufacturer Information
SHENZHEN SINOMATIC TECHNOLOGY CO, LIMITED, located in Shenzhen China, is a high-tech enterprise specializing in R&D, production and sales. Our product portfolio includes pedestrian access control turnstiles, vehicle barrier gates, hydraulic road bollards and blockers, and automatic gate operators. These solutions are deployed worldwide in government facilities, installations, educational institutions, healthcare facilities, airports, terminals, tourist attractions, and parking lots. Our products have been exported to over 100 countries including Italy, Germany, UK, Spain, Russia, Canada, Mexico, Brazil, UAE, India, Malaysia, Singapore, Thailand, South Africa, Nigeria, and Kenya. We prioritize stable functionality and excellent performance in product development while maintaining competitive pricing to establish long-term, mutually beneficial partnerships with our customers.
Joytech AC Motor PY1800AC Automatic Gate Opener For 1800kg Sliding Gate With 600w Rated Power
Important Safety Instructions

Read all instructions before installation. Incorrect installation may affect gate operation and safety.

Always disconnect power before mounting or positioning. Motor cover removal is required for mounting to the mounting plate or concrete footing. All settings adjustments must be performed by a licensed electrician. This product operates exclusively on AC110V/220V power supply and is not compatible with DC backup batteries or solar power systems.
