AC Model PY1200AC Automatic Gate Opener for 1200kg Sliding Gate With 450W Motor
AC Model PY1200AC Automatic Gate Opener for 1200kg Sliding Gate With 450W Motor
AC Model PY1200AC Automatic Gate Opener for 1200kg Sliding Gate With 450W Motor
AC Model PY1200AC Automatic Gate Opener for 1200kg Sliding Gate With 450W Motor
Specifications
Brand Name :
SINOMATIC
Model Number :
PY1200AC
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T, Western Union, , credit card/Cash/Alipay, L/C, D/A, D/P
Supply Ability :
10,000 pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Power Supply :
AC 220V/110V
Remote Control Code :
Rolling code
Drive Type :
Gear rack driven
Dimensions :
300 x 246.5 x 302mm
Max. Gate Weight :
1200kg/1800kg/2500kg
Frequency :
433.92MHz
Gross Weight :
9KG
Application :
Sliding door opener
Ip Level :
IP44
Manual Release :
Yes
Description
AC Model PY1200AC Automatic Gate Opener
Heavy-duty 450W motor automatic gate opener designed for commercial and industrial sliding gates up to 1200kg capacity and 12-meter operating distance.
Product Overview
  • NEW PY series gate opener for commercial and industrial applications
  • Oil lubrication system with heavy-duty construction
  • Compact, cost-effective design
  • Built-in control board or separate control box options
  • Keypad and single button interface
  • Alarm lamp, photo beam & safety beam interface
  • Auto-close function selection available
  • Optional spring limit switch or magnetic limit switch
  • Manual key release for emergency operation
  • Automatic obstacle detection with safety reversal (Smart version)
Technical Specifications
Model PY1200AC
Power Supply 220V/50Hz; 110V/60Hz
Max. Gate Weight 1200KG
Motor Power 450W
Gate Moving Speed 11-13 m/min
Limit Switch Spring (mechanical) / magnetic
Recording of up Remotes 20 pcs / 44 pcs
Decoding / Frequency Rolling code / 433.92MHz
Work Duty S2 20min
Noise ≤58dB
Work Temperature -20°C~70°C
Advanced Features
  • AC motor with built-in control unit
  • Keypad and single button interface options
  • Alarm lamp, photo beam and safety beam interfaces
  • User-selectable auto-close function
  • Soft start and slow stop operation (Smart version)
  • Auto-reverse function when hitting obstacles during closing (Smart version)
  • Manual key release for emergency operation
Standard Unit Includes
  • Gate Motor
  • Control board & box
  • 2 remote controls
  • Manual release key
  • User manual
  • Bolts & nuts
Optional Accessories
  • Metal Gear Rack & Nylon Gear Rack (order according to gate length)
  • Photo beam sensor
  • Keypad systems
  • Push button
  • Warning light
  • Solar panel
  • Backup batteries
About Our Company
SHENZHEN SINOMATIC TECHNOLOGY CO, LIMITED, located in Shenzhen China, is a high-tech enterprise integrating R&D, production and sales. Our main product lines include: Pedestrian access control turnstiles, Vehicle barrier gates, hydraulic road bollards and blockers, and Automatic gate operators. Our products are widely used in locations requiring access control, including government facilities, installations, schools, hospitals, airports, terminals, tourist attractions, and parking lots. Company products have been exported to over 100 countries worldwide, including Italy, Germany, UK, Spain, Russia, Canada, Mexico, Brazil, UAE, India, Malaysia, Singapore, Thailand, South Africa, Nigeria, and Kenya. We focus on stable function and excellent performance in product R&D, offering the most affordable prices to customers. Our goal is to establish win-win situations and long-term cooperation relationships with all customers and partners.
Company Certifications
AC Model PY1200AC Automatic Gate Opener for 1200kg Sliding Gate With 450W Motor
IMPORTANT SAFETY NOTICE
Instructions must be read before installation. Please follow these instructions carefully, as incorrect installation could affect gate operation.
When mounting and positioning this product, ensure the power cable is unplugged. The motor cover will need to be removed to mount the motor to the mounting plate or directly to the concrete footing. Any changes to the settings on this product can only be made by a licensed electrician. This product is only powered by AC110V/220V power supply; DC backup battery or solar power is not compatible.
