Single Lane Full-Height Gate Solenoid Lock Automatic 304 Stainless Steel
Single Lane Full-Height Gate Solenoid Lock Automatic 304 Stainless Steel
Single Lane Full-Height Gate Solenoid Lock Automatic 304 Stainless Steel
Single Lane Full-Height Gate Solenoid Lock Automatic 304 Stainless Steel
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-FH01
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T,Western Union,
Supply Ability :
200 pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Frame Material :
SS304 stainless steel
Transit speed :
30~35 person per min
Power voltage :
DC 24V / 50W
Passage Width :
≤650mm
IP Rating :
54
Operations time :
≥10 million times
Description
Single Lane Full-Height Gate Solenoid Lock Automatic 304 Stainless Steel
This semi-automatic stainless steel single lane full-height turnstile provides maximum access security control. Users cannot crawl underneath or climb over to gain unauthorized access. The full-height design effectively controls single passage each time, built with high-quality materials for advanced reliability and vandal resistance, making it suitable for outdoor usage in high-traffic environments.
Applications
Suitable for both indoor and outdoor applications. An economical solution for factories, colleges, commercial buildings, stadiums, game parks, prisons, and similar facilities.
Enhanced Security Features
A robust and durable gate is essential for outdoor security. The SINOMATIC SLAR (single-level anti-reverse) lock design prevents security loopholes where intruders might attempt to reverse rotation for unauthorized entry after a valid access.
Durability & Maintenance
The heavy-duty shock absorber reduces impact and vibration during operation, minimizing mechanical wear and lowering maintenance costs. The 304 stainless steel housing ensures long-lasting performance and vandal resistance.
Safety & Emergency Features
Manual unlocking capability during power failures allows free arm rotation for emergency escapes while maintaining security during normal operation.
Transportation & Assembly
The tripod arm is split into three separate pieces to reduce transportation costs, with easy on-site assembly.
Key Features
  • Minimum Maintenance: High-quality stainless steel housing with anti-rust and anti-septic treated internal parts for maximum durability
  • Convenience: LED light indicators show passage direction for user guidance
  • Easy Integration: Compatible with third-party access control or ticketing systems via external mounting or built-in options
  • Durable Construction: 304 stainless steel housing withstands 70kg resistant force when locked, suitable for indoor and outdoor use
  • Secure Operation: Anti-reverse smart locking system prevents unauthorized passage, allowing only one person at a time with a passage rate of approximately 30 persons/minute
  • Anti-Tailgating: Smart lock mechanism uses limit switches to detect rotation and re-lock after arm rotation exceeds halfway, preventing multiple entries
  • Power Failure Safety: Automatic arm unlocking during power outages with manual release capability
  • Memory Function: Records passage sequence and executes requests according to recorded patterns
Technical Specifications
Power Supply Input AC 220V 50HZ; 110V, 60HZ
Power Voltage DC 24V / 50W
Open Signal Passive signals (relay signals, dry contact signals)
Passage Width ≤650mm
Response Time ≤0.2s
Optimal Pass Speed 30-35 person/min
Housing / Arm 304 Stainless Steel
Arm Rotation Angle 90/120 degree
Working Environment Indoor and outdoor
Working Temperature -20°C to +70°C
IP Rating IP 54
Operations Time ≥10 million times
