Single Lane RS485 Full Height Turnstile with 2CBM Package Volume and IP54 Waterproof Security Pedestrian Gate
Single Lane RS485 Full Height Turnstile with 2CBM Package Volume and IP54 Waterproof Security Pedestrian Gate
Single Lane RS485 Full Height Turnstile with 2CBM Package Volume and IP54 Waterproof Security Pedestrian Gate
Single Lane RS485 Full Height Turnstile with 2CBM Package Volume and IP54 Waterproof Security Pedestrian Gate
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-FH01
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T,Western Union,
Supply Ability :
1,00pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Direction :
Single directional / Bi-directional
IP grade :
IP54
Package volume :
within 2CBM
Pass speed :
30 person/minute
Material :
SS304/316/ Carbon steel
Color :
Optional
Description
Single Lane RS485 2CBM Full Height Turnstiles Square Shape IP54
High Safety Single Lane Square Shape Full Height Turnstiles Security Pedestrian Gate
SINOMATIC 90 degree rod shaped pipes including centralized support for rotation bi-directional passage control.
These Full High Security Turnstiles are designed for applications requiring maximum security, including stadiums and arenas, perimeter and interior security, recreation and amusement parks, retail crowd control, transit fare collection, and high-security facilities such as prisons.
Technical Specifications
Size 1500×1500×2230mm
Material 1.2mm SS304 Stainless Steel
Pass Width 600mm
Passage Direction Single directional/Bi-directional
Pass Rate 30-35 persons/minute
Operating Time 0.2 seconds
Power Input AC100-240V, 50/60HZ
Working Humidity 30%~95%
Working Temperature -40℃~+70℃
Communication Interface RS485, Dry contact
Mechanism Solenoid Lock mechanism + cam + damper
MCBF 5,000,000 Cycles
Application Airports, Hotels, Government Halls, etc.
Single Lane RS485 Full Height Turnstile with 2CBM Package Volume and IP54 Waterproof Security Pedestrian Gate
Product Features and Functions
  • High security full height turnstiles providing efficient perimeter access control solutions
  • Durable construction with full body made of 304 stainless steel, including bars, mechanism, electric circuit, electromagnetic, hydraulic damper, and LED lamps
  • Standard fire interface allows arm free rotation for evacuation even without power cutoff during fire alarm
  • Ideal for both indoor and outdoor applications requiring high-level security and access control
  • Rotate range options: 90° rotor with 4 sectors or 120° rotor with 3 sectors for enhanced usability
  • Designed for high-security locations including prisons, stadiums, and construction sites
  • Single-door type with single/bi-directional passage control
  • Enhanced strength with wider passing width of 610mm
  • Waterproof, anti-corrosion, and rigid construction suitable for various environments
  • LED lights on top cover and body side indicate entry acceptance or denial status
  • Electric control system uses no motor drive for stable, reliable operation with low failure rate
  • Ultra-bright LED directional indicators for prominent visual guidance
  • Reverse alarm system alerts when pedestrian swipes card incorrectly
  • Anti-tailgating function: alarms when second person attempts passage without swiping card
  • Entry prompt system alerts when person enters passageway without swiping card
  • Multiple control functions including timed open mode for high-traffic periods
  • Flexible mode selection: two-way credit card, one-way credit card, or free pass options
  • Compatible with external button, remote control, bar code, IC or ID card systems
  • RS485 connectivity for computer integration and remote control functionality
  • Automatic reset function cancels passage authorization after 1-60 seconds if not used
