600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-SW01
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Motor :
24V BLDC motor
Arm material :
SUS304/Acrylic
Application :
indoor/outdoor
Optional :
counter, sensor
IP :
44
Power supply :
AC100V -240V, DC24V
Description
600mm Width IP44 Swing Barrier Gate with BLDC Motor
Supermarket RFID Card Reader Security Fully Automatic Swing Barrier Gate
Product Specifications
Appearance Size 168mm * Height 1010mm
Material Structure 304 Stainless Steel; 168mm pipe with 1.5mm thickness
Channel Width 600mm
Barrier Length Standard 600mm
Control Method Fully Automatic
Control Direction Single/Double Direction
Alarm Anti-pinch Mechanical anti-pinch to prevent bumps
Traffic Speed 30 people/minute
Working Power DC24V
Our Advantages
The stylish stainless steel column and clear toughened glass wing present a bright and concise design.
Bi-directional opening facilitates fast and safe access. It can also be integrated with recognition systems for user-friendly access control.
Featured with high security and stability, it's suitable for banks, corporate headquarters, airports and leisure venues.
Product Details
600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control 600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
Main Functions and Features
  • Stainless steel housing with rain-proof laser opening, novel and beautiful design
  • LINIX brush-less DC motor (premium Chinese micro-motor brand) with electroplated surface
  • Adjustable arm length: 500mm to 800mm
  • Fault detection and alarm functions for easy use and maintenance
  • Programmable running status controlled via built-in keyboard on main board
  • Mechanical anti-pinch function - motors stop automatically when meeting resistance and reset after delay
  • Anti-breakthrough function - gate remains locked until opening signal received
  • Synchronization functions for dual gate equipment
  • Automatic reset function - cancels user authority if not passed within prescribed time (default 5 seconds)
  • Configurable as normally open or normally closed
  • Compatible with various card readers: IC/ID card readers, bar codes, fingerprints (via dry contact signal)
  • Direction configurable as unidirectional or bidirectional
  • Connectable to management computer for remote control and management
  • Optional LED direction indicator
  • Fire safety compliant - auto opens when power off and auto closes when power on
  • Supports infrared photocell for anti-pinch and reset function
Production Process
600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control 600mm Width IP44 Swing Barrier Gate with BLDC Motor for Secure Pedestrian Access Control
Product Application
The brush-less anti-collision swing barrier is an intelligent passage management equipment developed and produced by our company. It integrates exquisite mechanical transmission, microprocessor control, voice and various reading and writing technologies. By configuring different reading and writing equipment, the intelligent control and management of the passage can be completed. The machine can realize the public channel's dissuade and access control for various secure environments.
