Specifications
Brand Name :
SINOMATIC
Model Number :
SN-FH01
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T,Western Union,
Supply Ability :
100 pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Power supply :
AC 220V/ AC110V ± 10%
Frame Material :
SS304
Transit speed :
25~30 person per min
Thickness of frame :
1.2 to 1.5mm
Arm length :
500mm to 550mm
Arm sections :
4 sections (90 degree)
Width of passage :
550mm to 600mm
Package :
Wooden box
Control Voltage :
DC24V
Surface treatment :
Brushed
Description
90 Degree Rotating Bi-Directional Turnstile with Biometric Fingerprint RFID Card Reader
Advanced full-height turnstile gate system featuring biometric fingerprint and RFID card reader technology for secure access control in industrial and commercial environments.
Product Overview
This full-height turnstile is engineered with robust mechanical construction to provide unsupervised access control for offices and buildings. The system enables intelligent pedestrian management while preventing unauthorized access to restricted areas through its impenetrable design.
Authorized passage requires presentation of a valid card to the access control system. Upon verification, the turnstile unlocks and permits passage in the requested direction. The system is compatible with push button controls, fingerprint scanners, and facial recognition technology.
Constructed from tailored stainless steel, this turnstile offers elegant aesthetics, exceptional durability, and superior anti-oxidation properties.
Technical Specifications
Lane Width 550-600mm (default)
IP Rating IP54
Pass Speed 30 persons/min
Power Supply AC220V/110V, 50/60Hz
Drive Mode Motor free
Max Power Consumption 200W
Unlock Time 0.2S
Humidity ≤90% coagulation free
Noise Level ≤50dB
Service Life 5,000,000 cycles
Working Environment -20°C to +60°C
Gross Weight 350KGS
Product Dimensions
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
Key Features & Functions
  • Low noise mechanism core for high cost-performance operation
  • High operating efficiency with less than 1 second open & close time
  • Self-checking and alarm warning for maintenance alerts
  • Automatic resetting cancels authorized pass if passenger delays
  • Anti-following technology prevents illegal passing
  • Anti-clamp safety feature stops wings during external blocks
  • Automatic locking if person fails to pass within designated time
  • Multi-passage configuration for various application demands
  • Programmable signal separate control for pass time and speed parameters
  • Compatible with RFID card readers, fingerprint readers, and facial recognition systems
  • Long-distance management capabilities through computer interface
  • Customizable options including LED display, voice guidance, warning lamps, indicator lights, and audible/visible alarms
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
Control & Interface Options
  • Card readers for access control
  • Metal detection capabilities
  • Electronic/LCD counters
  • Fail-open or fail-secure locking modes
  • Push-button and wireless remote controls
  • Manual key override for both directions
  • Indicator lights for status monitoring
Manufacturing & Quality
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
Packaging & Shipping
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame 90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame 90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
System Operation
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
Installation References
90 Degree Rotating Bi-directional Full Height Turnstile with Biometric Fingerprint RFID Card Reader and SS304 Frame
