Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control
Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control
Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control
Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control
Specifications
Brand Name :
SINOMATIC
Model Number :
SN-SW
Certification :
CE/ ISO
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
negotiable
Payment Terms :
T/T,Western Union,,L/C,D/A,D/P
Supply Ability :
3,000pcs per month
Delivery Time :
5-10 working days after payment received
Packaging Details :
Carton/Plywood box/Pallet
Case material :
304 stainless steel
Arm material :
Acrylic or SS304
Product life :
More than 5 million times
Motor :
24VDC
Direction :
Single or bi-direction
LED indicator :
included
Description
Anti Pinch 35W Swing Arm Barrier Electronic 24VDC For Security Check
220V 110V electronic 2 channel swing arm barrier, controlled access turnstiles for security check
Swing Arm Barrier Introduction
Swing turnstiles are compact and cost-effective entrance solutions designed for controlled access management.
  • Constructed with brushed stainless steel for robust, rigid, anti-rust and durable performance
  • Ideal for both indoor and outdoor installations (with protective shelter)
  • Compatible with various access control systems including RFID, push button, fingerprint and biometric devices
Key Features
  • Working method configurable via main panel buttons
  • Anti-pinch and anti-collision safety features with automatic motor stop and 2kg force limitation
  • Anti-illegal entry and anti-intrusion protection with auto-close for reverse direction
  • Automatic closure when no valid signal is detected
  • Motor protection from external force collisions
  • Synchronized gate operation capability
  • Auto-reset function with adjustable timing (1-60 seconds, default 10s)
  • Reset and anti-pinch functions via photocells
  • Compatible with access control, consumption, ESD, and e-ticket systems
  • One-way or two-way control options
  • Remote control administration capability
  • LED lamp indicator for status monitoring

Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control

Technical Specifications
Framework Material 304 Stainless Steel
Dimension 1200 × 280 × 980mm
Net Weight 80kg
Passage Width 960mm (One passage)
Passing Direction Single directional / Bi-directional
Power Supply 100V~240V, 50/60Hz
Operation Voltage 24V DC
Power Consumption 35W
Operation Temperature -20°C to +60°C
Operation Humidity 0 to 95% (No freeze)
Working Environment Indoor / Outdoor (Shelter)
Flow Rate 30-35 people per minute
LED Indicator Yes
Infrared Sensor Yes
Emergency Feature Automatic arm open when power off
Production Line
Anti Pinch 35W Swing Arm Barrier with 24VDC Motor for Secure Access Control
Our Manufacturing Advantages
  • Professional security solutions
  • Competitive and reasonable pricing
  • Advanced manufacturing technology
  • High quality construction standards
  • Fast delivery service
  • Comprehensive customer support
  • Industry-leading reputation
  • Expert engineering team
  • Wide range of application scenarios
