Specifications
Exhaust :
Round / 200mm
Place of Origin :
Guangdong / Dongguan
Comm Port :
USB
Voltage :
220VAC / 50Hz
Packaging Details :
wooden box
Key Parts :
Leadshine Motor / HIWIN Guide / NSK Bearing
Gun / Nozzle :
WA101 Spray Gun, 0.5mm
Program :
10,000+
Model Number :
200X7B
Price :
￥48800 | $7176
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Material :
Stainless Steel / Aluminum / Steel
Air Pressure :
0.4-0.6MPa
Axes :
X(Left/Right) / Y(Front/Back) / Z(Up/Down) / U(Gun 360 Rotate) / V(Station A Rotate) / W(Station B Rotate)
Brand Name :
Man Sheng
Drive :
7-Axis Closed-Loop Stepper Drive
Dimension :
1030 x 1000 x 1750mm (Frame: 825mm)
Power :
0.75KW/H
Spray Range :
200 x 200mm
MOQ :
1
Accuracy :
0.05mm
Spray Mode :
360 Rotation + Reciprocating (2 guns, independent oil output)
Weight :
230KG
Effective Stroke :
290 x 240 x 160mm
Control :
Touch Screen
Description

Product Specifications

ParameterSpecification
Model200X7B Hinge Mold Auto Spray Machine
MaterialStainless Steel / Aluminum / Steel
Weight230KG
Gun / NozzleWA101 Spray Gun, 0.5mm
Dimension1030 x 1000 x 1750mm (Frame: 825mm)
Effective Stroke290 x 240 x 160mm
Spray Range200 x 200mm
Spray Mode360 Rotation + Reciprocating (2 guns, independent oil output)
Drive7-Axis Closed-Loop Stepper Drive
AxesX(Left/Right) / Y(Front/Back) / Z(Up/Down) / U(Gun 360 Rotate) / V(Station A Rotate) / W(Station B Rotate)
Accuracy0.05mm
ControlTouch Screen
Program10,000+
Comm PortUSB
Key PartsLeadshine Motor / HIWIN Guide / NSK Bearing
Voltage220VAC / 50Hz
Air Pressure0.4-0.6MPa
ExhaustRound / 200mm
Power0.75KW/H

Key Selling Points

  • 7-Axis Ultra-Precision System: 0.05mm positioning accuracy with closed-loop stepper drive, ensures consistent, defect-free coating for hinge mold and small parts.
  • Dual Independent Spray Guns: 2x WA101 spray guns (0.5mm nozzle) with separate oil output control, supports 360 rotation + reciprocating spraying for full coverage.
  • Compact and Versatile Design: 200 x 200mm spray range, dual-station rotation, and 10,000+ programmable sequences, ideal for hinges, auto parts, 3C electronics and small metal components.
  • Durable Industrial Build: Features HIWIN linear guides, NSK bearings, and brand-name components; 230KG stable frame, runs on 220VAC/50Hz with 0.4-0.6MPa air pressure.
  • Energy-Saving and Easy to Operate: Only 0.75KW/H power consumption, touch screen control with USB port, 200mm round exhaust for clean working conditions.
