Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
Specifications
Brand Name :
Shiyuan
Model Number :
SLIV-520TB
Certification :
CE
Place of Origin :
Foshan
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
100 Set/Month
Delivery Time :
15 - 25 / day
Packaging Details :
1420 ( L ) x 1937 ( W ) x 2148 ( H ) mm
Packaging Materials :
PE (composite film)
Packing speed :
5 - 60 bags/minute
Maximum film width :
520mm
Maximum bag length :
400mm
Air pressure :
0.65mpa
Air consumption :
0.6m3 / min
Voltage :
220V / 50Hz
Power :
5.5KW
Product Size :
1420 ( L ) x 1937 ( W ) x 2148 ( H ) mm
Weight :
600Kg
Name :
Granule Packing Machine
Description

Automatic Peanut Grain Packing Machine 100g 200g 500g

Features


1. The new design, beautiful appearance, the structure is more reasonable, more advanced technology.
2. English and Chinese screen display. PLC control, servo motor, very easy to operate. Do not need to stop machine to adjust any parameters.
3. Fully automatic bag forming, dosing Filling, sealing, coding, conveying, counting can be finished in one operation, most labor-saving equipment.
4. High quality stainless steel, suitable for GMP, good for food packaging with high standard.
5. Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
6. Pocket diversification, can provide customers with pillow bags, angled bags, hanging-hole bags, vertical bags, punched bags, etc.
7. A variety of automatic alarming protective function, maximum limit to reduce wear and tear.
8. Double sever motors, drawing film position accurately, and the speed is faster.
9. Temperature independent control system, precision get to ±1°C.

Granule Packaging Machine Specification

Model
SL - 520TB Edge Pressing Machine
Packaging material
Composite membrane
Maximum measurement range
3000ML
Bag size
Positive width 8 - 150mm ( without ironing edge )
Side width
40 - 100mm ( without ironing edge )
Bag length
350mm
Packing speed
5 - 40 bags / minute
Maximum width of roll film
520mm
Voltage
220VAC / 50HZ
power
6KW
Package Size
1900L * 1450W * 2270H
Machine weight
Gross weight 550KG

Automatic Peanut Packing Machine 100g 200g 500g Grain Packing Machine
