RVV Flexible PVC Jacket Flat Wire Electrical Cable for Easy Installation and Maintenance in Industrial Applications
RVV Flexible PVC Jacket Flat Wire Electrical Cable for Easy Installation and Maintenance in Industrial Applications
Specifications
Brand Name :
sihuan
Model Number :
electric wire 2x2.5mm2
Place of Origin :
china
Package Gross Weight :
250.000kg
Insulation Material :
PVC
Conductor Type :
Stranded
Standard :
GB/T5023.3
Temperature Rating :
90°C
Core Number :
2-60
Sample :
Provided
Sheath Material :
PVC
Description

RVV Flexible PVC Jacket Flat Wire Electrical Cable – Overview

RVV (PVC Insulated PVC Sheathed Flexible Cable) is a multi-core flat wire widely used in household appliances, power connections, control circuits, and signal transmission. It features PVC insulation and sheath, offering flexibility, durability, and resistance to abrasion and moisture.

Key Features:

  • Conductor: High-purity copper (stranded for flexibility)

  • Insulation & Sheath: PVC (flame-retardant, UL/CE/CCC certified)

  • Voltage Rating: 300/500V

  • Temperature Range: -15°C to +70°C

  • Core Configurations: 2/3/4/5 cores (common sizes: 0.75mm²–6mm²)

  • Applications: Extension cords, power tools, lighting circuits, control panels

Technical Specifications Table

Parameter Specification
Conductor Material Oxygen-free copper (99.9%)
Conductor Type Stranded (Class 5 flexibility)
Insulation Material PVC (Polyvinyl Chloride)
Sheath Material PVC (flame-retardant)
Rated Voltage 300/500V
Max. Operating Temp. 70°C (158°F)
Bending Radius ≥6× cable diameter
Core Options 2/3/4/5 cores
Conductor Size 0.5mm²–6mm² (common: 0.75mm², 1.5mm², 2.5mm²)
Standards Compliance GB/T 5023.5, IEC 60227, CCC, CE, RoHS
Fire Resistance IEC 60332-1 (flame-retardant)
Color Coding Black, white, red, blue, yellow/green (earth)

Applications

  • Household Wiring: Power strips, lighting circuits, small appliances.

  • Industrial Use: Control panels, machinery connections.

  • Low-Voltage Systems: Security alarms, intercoms, automation controls.

Advantages

  1. Flexible & Durable: Stranded copper allows easy bending for tight spaces.

  2. Double Protection: PVC insulation + sheath for enhanced safety.

  3. Cost-Effective: Affordable for general-purpose wiring.

Comparison with Similar Cables

Feature RVV RV RVVP
Structure Multi-core + PVC sheath Single-core, no sheath RVV + shielding layer
Voltage Rating 300/500V 450/750V 300/500V
Flexibility High Very High Moderate
Typical Use Power/control wiring Industrial controls Anti-interference signal lines

s.
