Mining Box Type Rock Breaker Hammer Chisel Dia 135mm For 18-26Ton Excavators
Mining Box Type Rock Breaker Hammer Chisel Dia 135mm For 18-26Ton Excavators
Mining Box Type Rock Breaker Hammer Chisel Dia 135mm For 18-26Ton Excavators
Mining Box Type Rock Breaker Hammer Chisel Dia 135mm For 18-26Ton Excavators
Specifications
Brand Name :
YTCT
Model Number :
YTCT70
Certification :
CE/ISO
Place of Origin :
Yantai, China
MOQ :
1
Price :
786-11,349 USD/Unit
Payment Terms :
L/C, D/P, T/T
Supply Ability :
1000 Unit per month
Delivery Time :
5-8 Working Days
Packaging Details :
Wooden box
Color :
Any Color/ Customization
Application :
Mining, Demolition, Construction, Excavation, Quarrying, Earthmoving
Condition :
New
Warranty :
12 Month
Oil Flow :
120-180L/min
Video Outgoing-Inspection :
Provided
Description

Chisel Diameter 135mm Silenced Box Type Excavator Rock Breaker Hammer For18-26Ton Excavators

Box Type Hydraulic Hammer Specification:

YAKAI Silent Type Rock Breaker Parameter Chart
Model

Body Weight (incl. chisel tool)

(kg)

Total Weight

(kg)

Size (L*W*H)

(mm)

Working Oil Flow

(I/min)

Hydraulic Pressure

(kg/cm^2)

Blow Frequency

(bmp)

Chisel Diameter

(mm)

Carrier Weight

(ton)

Rock Drill Breaker for Mini Excavator
YTCT05 60 95 990*235*255 15-20 80-110 850-1350 35 0.8-1
YTCT10 68 100 1030*240*265 20-30 90-120 800-1300 40 0.8-1.5

Hydraulic Breaker for Light Weight Excavator
YTCT20 71 129 1331*260*265 20-30 90-120 700-1200 45 1.2-3.0
YTCT30 89 155 1417*350*305 25-50 90-120 600-1100 53 2.5-4.5
YTCT40 156 361 1660*328*486 40-70 110-140 500-900 68 4-7
YTCT43 214 450 1712*328*486 50-90 120-150 400-800 75 6-9
YTCT50 479 1007 2345*440*570 80-110 150-170 350-700 100 10-15

Rock Breaker for Medium Duty Carrier
YTCT70 850 1898 2847*560*710 130-150 160-180 400-800 135 18-26
YTCT81 920 2004 2793*560*710 120-180 160-180 350-500 140 18-26
YTCT81A 956 2042 2793*560*710 120-180 160-180 350-500 140 18-26
YTCT100 1092 2457 3002*640*760 150-190 160-180 350-700 150 27-35
YTCT121 1313 2968 3075*640*760 180-240 160-180 300-450 155 28-35

Hydraulic Hammer for Heavy Duty Excavators
YTCT131 1442 2916 3337*654*840 200-260 160-180 250-400 165 30-45
YTCT140 1590 3116 3541*664*875 200-260 160-180 250-380 165 30-45
YTCT151 1925 3906 3723*670*920 210-290 160-180 200-350 175 40-55

* The Parameter above may change with the technology improvement, will not notice additionally, please understand.

Hydraulic Rock Breaker Applications:

1. Mining: Mountain excavation, mining, expolosion

2. The metallurgical: slag cleaning, furnace body, equipment foundation demolition

3. The railway: tunnel tunneling, road and bridge demolition, subgrade tamping

4. The highway: Highway repairing, cement pavement breakage, foundation excavation

5. Municipal gardens: Concrete crushing, water, electricity, gas engineering construction, old city transformation

6. Building: Old buildings demolished, reinforced concrete broken

7. The ship: Hull clam removal, rust removal

8.Breaking ice, breaking frozen soil, sand vibration

Excavator Hammer Features:

  1. Selection of raw materials - high quality heavy wear resistant steel.
  2. Using of hydraulic nitrogen system to increase stability
  3. High quality durable wear-resistant parts
  4. Advanced manufacturing facilities.
  5. High energy and impact frequency (high performance)
  6. High performance optimized hydraulic unit
  7. Less maintenance, less failure, long service life
  8. Fully enclosed shell structure
  9. Vibration and noise damping system
