Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
Specifications
Brand Name :
YOUNGYOU
Model Number :
YYSC11
Certification :
CE
Place of Origin :
CHINA
MOQ :
2
Price :
800
Payment Terms :
L/C, T/T
Supply Ability :
100 sets/ month
Packaging Details :
Foam protection+carton packaging
IP level :
IP 54
Weight :
2.5kg
L*W*H :
308mmx86mmx114mm
Propeller size :
M1.6 ; M2 ; M2.5 ; M3 ; M4 ; M5 ; M6
Screw specification range :
M1.6 ; M2 ; M2.5 ; M3 ; M4 ; M5 ; M6
Output speed :
340 RPM
Description

Robotic screw locking machine using integrated, electric brushless DC motor

Intelligent Screwdriver, easy to realize the fastening process of multiple screws
To avoid downtime due to manual conversion
• Optimal working state - consistent, fast - with dynamic force
Control and intelligent error detection
• Expand the possibility of collaborative automation with built-in protection

NO Name Description unit
1 Processable materials Plasticmetalwood
2 Screw specification range M1.6~M6
3 Torque range 0.04~5 Nm
4 Torque accuracy

If torque<1.33Nm/0.98lbft,

0.04Nm/lbft
5 Torque accuracy

If torque>1.33Nm/0.98lbft.3,

3%
6 Output speed max 340 RPM
7 Screw length in full safety zone 35/1.37 mm/inch
8 Handle stroke (screw shaft) 55/2.16 mm/inch
9 Force of safety facilities

35~45

 N
10 IP level IP54
11 Size 308*86*114(mm). 12.1*3.4*4.5(inch)
12 Weight 2.5 kg
13 Propeller size M1.6;M2;M2.5;M3;M4;M5;M6

Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor

Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor

Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor

Product characteristics

Arm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC MotorArm Robot Screwdriver Robotic Screw Locking Machine Using Integrated Electric Brushless DC Motor
