Product image shows a rugged outdoor enclosure with integrated antenna dome, eliminating the need for external antennas. The device measures 27 x 23 x 24 cm and includes mounting hardware for pole or wall installation.

• Integrated Antenna Design: Features internal directional antennas with 90°H x 90°V beamwidth, eliminating the need for external antennas and simplifying deployment in outdoor environments.
• Rugged Outdoor Construction: IP67-rated weatherproof enclosure designed to survive extreme temperatures (-40°C to +65°C), persistent moisture, airborne contaminants, and high wind speeds.
• High-Performance Wi-Fi 5: Delivers up to 2.69 Gbps aggregate throughput with dual-radio 4x4/2x2 MIMO, ensuring reliable performance for demanding outdoor applications.
• IoT-Ready Platform: Integrated Bluetooth 5 and 802.15.4/Zigbee radios enable smart city and industrial IoT applications without additional infrastructure.
• Simplified Deployment: Integrated antennas reduce installation complexity and cost while maintaining optimal RF performance for most outdoor scenarios.

The HPE Aruba Networking AP-575 (RW) is a rugged outdoor Wi-Fi 5 (802.11ac Wave2) access point from the Aruba 570 Series, featuring integrated directional antennas for simplified deployment in outdoor environments. This design eliminates the complexity of external antenna selection and installation while delivering reliable performance for stadiums, public venues, industrial sites, and smart city deployments.

The AP-575 features integrated directional antennas with 90°H x 90°V beamwidth, providing focused coverage ideal for pathways, building perimeters, and targeted outdoor areas. Antenna gain is 6.4 dBi on 2.4 GHz and 6.3 dBi on 5 GHz, ensuring robust signal propagation. The dual-radio configuration with 4x4 MIMO on 5 GHz and 2x2 MIMO on 2.4 GHz delivers up to 2.69 Gbps aggregate throughput.

The IP67-rated rugged enclosure protects against extreme temperatures (-40°C to +65°C), persistent moisture, precipitation, airborne contaminants, dust, and salt sprays. This ensures reliable operation in coastal areas, industrial facilities, and regions with extreme weather conditions. The device can withstand high wind speeds common in outdoor deployments.

Integrated Bluetooth 5 and Zigbee radios enable IoT applications such as asset tracking, environmental monitoring, and smart city services without requiring separate infrastructure. The AP-575 can be managed through HPE Aruba Central for cloud-based oversight with AI-powered analytics, or through on-premises controllers, with Zero Touch Provisioning enabling rapid deployment at scale.

The AP-575 features built-in directional antennas with 90°H x 90°V beamwidth, eliminating the need for external antenna selection, procurement, and installation. This simplifies deployment while providing optimal RF performance for targeted coverage scenarios.

IP67-rated enclosure provides complete protection against dust and water ingress, with the ability to withstand temporary immersion in water. The device operates reliably in temperatures from -40°C to +65°C and resists damage from high wind, precipitation, and airborne contaminants.

With 4x4 MIMO on 5 GHz and 2x2 MIMO on 2.4 GHz, the AP-575 delivers up to 2.69 Gbps aggregate throughput, ensuring robust performance for bandwidth-intensive outdoor applications. MU-MIMO enables efficient multi-user communication in dense environments.

EN 50155 and EN 50121 certification make the AP-575 suitable for deployment in railway applications including stations, platforms, and rolling stock, where vibration, shock, and temperature extremes are concerns.

Integrated Bluetooth 5 and Zigbee radios enable a wide range of IoT applications without additional infrastructure. The AP-575 can serve as a converged IoT gateway for asset tracking, environmental monitoring, and smart city services.

The Policy Enforcement Firewall automatically enforces consistent security policies across wired and wireless connections based on user identity and device type, eliminating complex VLAN and ACL management while ensuring traffic isolation and protection.

Integration with HPE Aruba Central provides a single pane of glass for overseeing outdoor wireless networks with AI-powered analytics, end-to-end orchestration, and automation capabilities. Zero Touch Provisioning enables rapid deployment at scale.

Ideal for providing directional coverage in stadium seating areas, concourses, and VIP suites. The integrated antennas deliver focused coverage exactly where needed, while rugged construction ensures reliable operation in all weather conditions.

EN 50155 certification makes the AP-575 perfect for railway applications including passenger platforms, waiting areas, and station buildings where reliable wireless connectivity is essential for operations and passenger experience.

Provides targeted coverage along building exteriors, loading docks, and security perimeters. The directional antennas focus RF energy exactly where needed, minimizing interference and maximizing coverage efficiency.

Supports wireless connectivity in factories, warehouses, and refineries where directional coverage is needed along specific pathways or work areas. The rugged enclosure protects against industrial contaminants and extreme temperatures.

Delivers focused coverage in amphitheaters, picnic areas, and event spaces where targeted wireless coverage is needed without spillover into adjacent areas. Simplified deployment reduces installation costs for municipal Wi-Fi projects.
