R4W43A HPE Aruba Networking AP565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP
R4W43A HPE Aruba Networking AP565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP
Specifications
Number of Ports :
8 / 16 / 24 / 48
Switching Capacity :
48 Gbps
Certification :
CE, FCC, ROHS, CCC, ISO9001
Port Speed :
1 Gbps
Warranty :
3 years
Place of Origin :
VIETNAM
Port Count :
24 ports
Management Interface :
Web GUI, CLI, SNMP
Model Number :
R4W43A AP-565 (RW)
Power Consumption :
15W
VLAN Support :
Yes, up to 4096 VLANs
Delivery Time :
24-48 Hours
Switch Type :
Managed / Unmanaged
Layer :
Layer 2 / Layer 3
Power Supply :
AC 100-240V
MOQ :
1
Packaging Details :
60cmx60cmx19cm
Management :
Web GUI, CLI, SNMP
PoE Support :
Yes, up to 30W per port
MTBF :
500,000 hours
Supply Ability :
200
Forwarding Rate :
35.7 Mpps
Dimensions :
440 x 220 x 44 mm
Payment Terms :
T/T,Western Union
Power over Ethernet (PoE) :
Supported / Not Supported
Weight :
2.5 kg
Quality of Service (QoS) :
Supported
Brand Name :
HPE ARUBA
Operating Temperature :
0°C to 40°C
Description
R4W43A HPE Aruba Networking AP 565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP

The HPE Aruba Networking 560 Series Outdoor Access Points provide cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the 560 series delivers the speed and reliability needed to bring medium-density Wi-Fi 6 outdoors.

R4W43A HPE Aruba Networking AP565 (RW) 802.11ax Dual 2x2 Radio Integrated Omni Antennas Outdoor AP

These Wi-Fi 6 outdoor access points are ready to survive high wind, extreme temperatures, and moisture and can be quickly deployed using zero touch provisioning (ZTP). HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and virtual private networks (VPNs). AI powered analytics, end to end orchestration and automation, and advanced security features are built natively into the solution. The 560 series outdoor APs include a limited lifetime warranty.

What's New
  • Entry-level outdoor Wi-Fi 6 (802.11ax) access points that provide up to 1.49 Gbps peak aggregate data rate and are ideal for outdoor and warehouse environments
  • Purpose-built to survive in the harshest outdoor environments and extreme temperatures (-40˚C to +55˚C)
  • Ready for Internet of Things (IoT) with a built-in Bluetooth 5 and 802.15.4 radio that supports Zigbee
  • Small form factor for flexible deployment.
  • Client and RF optimization to match clients with the best available access point and reduce coverage gaps
  • Dynamic segmentation and policy enforcement firewalls (PEFs) that automatically enforce consistent policies across all networks, keeping users and devices secure
Specifications
Feature Detail
Deployment Outdoor
Wi-Fi generation Wi-Fi 6 (802.11ax)
Wi-Fi radios Dual 2x2
Radio configuration options 2.4 GHz and 5 GHz
Max bandwidths and peak data rate per band 20/40 (2.4GHz), 20/40/80 (5GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps
Wi-Fi antenna Built-in omnidirectional antennas with 5.4 dBi gain maximum, for 5 GHz antennas and 3.2 dBi gain maximum for 2.4 GHz antennas
Ultra tri-band (UTB) filtering No
IoT support IEEE 802.15.4/Zigbee or Bluetooth 5
Integrated sensor No
Location services 802.11 FTM support
Cellular support No
Wired network interface 1 x 1GbE
MACsec support No
Ports E0: 10/100/1000BASE-T (RJ-45)
USB-C console interface
Power sources PoE-PD
AP operating system support HPE Aruba Networking Wireless Operating System 8 and HPE Aruba Networking Instant OS 8.7.1.0
HPE Aruba Networking Wireless Operating System 10.3.0.0
AP management On-premises; Public Cloud; Virtual Private Cloud (VPC); as a Service
Certifications
  • CB Scheme Safety, cTUVus
  • UL2043 plenum rating
  • Wi-Fi Alliance® certified 802.11a/b/g/n/
  • Wi-Fi Alliance certified Wi-Fi 6 (802.11ax)
  • Wi-Fi CERTIFIED® ac (with wave 2 features)
  • Wi-Fi CERTIFIED Location
Regulatory
  • FCC/ISED
  • CE Marked
  • RED Directive 2014/53/EU
  • EMC Directive 2014/30/EU
  • Low Voltage Directive 2014/35/EU
  • IEC/EN/UL 62368-1
  • EN 60601-1-1, EN60601-1-2
  • Railway Certs:
  • EN 50155:2017—Railway Applications
  • EN 50121-1:2017—Railway EMC
  • EN 50121-3-2—Railway EMC
  • EN 50121-4:2016—Railway Immunity
  • IEC 61373 ed2:2008—Railway Shock and Vibration
  • For more country-specific regulatory information and approvals, contact your HPE representative.
Warranty Limited lifetime warranty. See the warranty duration.
Shipping dimensions 165 x 165 x 130 mm (6.5 X 6.5 X 5.1 in)
