Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming
Specifications
Model Number :
ZW11 Pro
Detection Range :
5km (line-of-sight environment, electromagnetic noise: -90 dB to -95 dB)
MOQ :
1
Packaging Details :
Aluminum box
Positioning distance :
DID ≥ 5 km, RID≥2 km (suburban line-of-sight environment, electromagnetic environment noise: -90～-95dB);
Weight :
≤170 kg
Payment Terms :
T/T
Jamming Frequency Band :
700MHz-840MHz, 860MHz-930MHz, 1170MHz-1290MHz, 1400MHz-1490MHz, 1560MHz-1620MHz, 2385MHz-2490MHz, 5150MHz-5250MHz, 5725MHz-5850MHz
Certification :
CE
Key detection frequency bands :
433 MHz, 530 MHz, 750 MHz, 800 MHz, 900 MHz, 1.2 GHz, 1.4 GHz, 2.4 GHz, 3.3 GHz, 5.2 GHz, 5.8 GHz
Delivery Time :
7-10 working days
Overall power consumption :
≤100 W
Dimensions :
1367mm / 1013mm / 2661mm (L / W / H)
Brand Name :
Roviyno
Detection Frequency :
Full-band 70 MHz - 8 GHz (including spectrum analysis function)
FPV video transmission detection :
≥1.5 km (Supports real-time video viewing, environmental line of sight, analog image transmission power ≥2.5 W)
Supply Ability :
<100 units 30 working days
Jamming Distance :
≥3km (Depends on working conditions)
Protection level :
IP66
Place of Origin :
China
Extended detection band :
6GHz-8GHz detection
Description

Fixed UAV Detection & Jamming Equipment: 10km Detection + Positioning + 3km Jamming

Product Introduction

By detecting, identifying, locating, defending, and managing civil low-altitude, slow-moving, and small drones, it can highly meet the low-altitude security needs at home and abroad. The equipment can perform passive detection on drones in the control area, distinguish between friend and foe, and carry out precise strikes or high-power interference.


Smart UAVs Control System adopt the technology of Cognitive Radio Protocol Cracking, it is a low altitude security system used for civil UAV detection, identification, positioning, defense and control. The system can carry out passive detection, distinguish between legal and illegal, precise neutralize or high-power interference UAV. It can be used for low-altitude security defense of airports, prisons, important bases, sports venues and major events.


Cognitive Radio Protocol Cracking technology is the fourth generation of UAV defense, by using this technology can accurately demodulate the UAV communication frequency band, channel information and electronic ID through reverse analysis and cracking of UAV communication signals, based on the acquired information, illegal UAVs will be targeted for defense and precise control.

Product Feature
    1. Integrated Detect-and-Defend Solution A seamless fusion of radio detection, protocol decoding, electromagnetic jamming, and navigation spoofing, providing a full-process defense cycle from autonomous discovery to real-time neutralization.
    2. Advanced FPV Countermeasures Specifically engineered to capture FPV video transmission signals and deliver high-intensity interference, effectively neutralizing high-speed and highly maneuverable drone threats.
    3. Precision Navigation Spoofing Features rapid-activation (<4s) navigation spoofing for GPS, GLONASS, and BeiDou, enabling tactical redirection or forced landing of intruding UAVs.
    4. Full-Spectrum Multi-Sensor Fusion Utilizes multi-sensor technology to cover an ultra-wide scanning range from 70MHz to 6GHz, ensuring 360° situational awareness of mainstream, DIY, and non-standard drones.
    5. High-Capacity Networked Linkage Supports a “one-detection, multiple-jamming” scalable architecture, allowing seamless integration across nodes for unified command in large-scale urban or critical infrastructure protection.

Fixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km JammingFixed UAV Detection And Jamming Equipment 10km Detection Positioning 3km Jamming

Product Specificaiton
Technical Parameter Specification
Detection frequency band 70MHz-8GHz
Key detection frequency bands 800MHZ,900MHz,1.2GHz,1.4GHz,2.4GHz,5.2GHz,5.8GHz
Detection range ≥10km (Depends on working conditions)
FPV Video transmission detection 500MHz-6GHz full-frequency scanning, detection and display
Video transmission detection range ≥1.5km(Supports viewing real-time video)
Jamming Frequency Band 700MHz-840MHz, 860MHz-930MHz, 1170MHz-1290MHz, 1400MHz - 1490MHz, 1560MHz-1620MHz, 2385MHz-2490MHz, 5150MHz-5250MHz, 5725MHz-5850MHz
Jamming Distance ≥3km (Depends on working conditions)
Azimuth range Horizontal: 360°,Pitch: 90°
Operation temperature -40°C~+60°C
Weight ≤170kg
Size 1367mm / 1013mm / 2661mm (L / W / H)
Product selling points
  1. Long Detection Range: 5-10 km line-of-sight detection; 2-10 km DID/RID positioning; ≥1.5 km FPV video interception;
  2. Full-band detection coverage: 70 MHz--8 GHz full spectrum scanning, supports spectrum analysis;
  3. 360° omnidirectional monitoring: No blind zone, full azimuth coverage;
  4. Ultra-fast response: Drone detection alarm ≤5 seconds;
  5. High-Precision Positioning: ≤1 meter latitude/longitude accuracy with real-time trajectory tracking;
  6. Triple alarm mode: Sound + light + vibration real-time alert.
  7. Multi-band interference:700MHz-840MHz, 860MHz-930MHz, 1170MHz-1290MHz, 1400MHz - 1490MHz, 1560MHz-1620MHz, 2385MHz-2490MHz, 5150MHz-5250MHz, 5725MHz-5850MHz
