Specifications
Brand Name :
AND
Model Number :
MD5381
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
Before T/T ; L/C
Delivery Time :
1-4 weeks
Packaging Details :
Paper Box
Name :
Machine Load Smart Screwdrivers
The power of motor :
AC 100W
Max. speed (rpm) :
1200
Rated torque(N . m) :
3.0
Batch Head :
Hexagon (Hex) (6.35mm)
Description

Machine-loading Smart Screwdriver MD5381 Support the dummy-proof and error-proof factory control systems

MD5381Machine-loading Smart Screwdriver


Professional concept of modular and combined design solution

Leading servo motor drive plus precision reduction structure

Blow/suction optional automatic feeding method

Safe and reliable special cable and connector configuration

Multi-style, multi-series and multi-specification product selection

Beautiful and compact appearance structure, convenient and flexible installation method and suitable for a variety of applications

This model can only works properly with ACT series controller ACT-M11** and has a great balance between the need for high torque and high efficiency.

The torque output range of this model is 0.8-3N.m.

The maximum speed is 1200 rpm with the weight about 1.3 kg.

It works with the hexgon type of screwdriver bits (6.35mm).

Dimensions (mm)

MD5381 Error Proof Torque Electric Screwdriver AC 100W With Hex Batch Head

specifications

Model Adapted
controller		 Tool cable Torque output range Maximum
Speed
(rpm)		 Weight
(kg)		 Applicable
batch head		 Adapted outer diameter of screw(mm)
kgf.cm N.m lbf.in
MD2120 ACT-M00XX
HNA-M21XX		 C112X 0.20～2.35 0.02～0.23 0.18～2.04 5000 0.5 Tail 1.0～2.0
MD2121 Hex(6.35mm)
MD2350 ACT-M01XX
HNA-M23XX		 1.52～9.18 0.15～0.90 1.33～7.97 1200 0.7 Tail 2.0～3.0
MD2351 Hex(6.35mm)
MD2460 ACT-M02XX
HNA-M24XX		 2.00～12.23 0.20～1.20 1.77～10.62 1000 0.7 Tail 2.0～4.0
MD2461 Hex(6.35mm)
MD5151 ACT-M10XX C212X 2.04～9.18 0.20～0.90 1.77～7.97 5000 1.0 Hex(6.35mm) 1.8～3.0
MD5152 Hex(4mm)
MD5381 ACT-M11XX 8.16～30.60 0.80～3.00 7.08～26.55 1200 1.3 Hex(6.35mm) 2.5～5.0
MD5382 Hex(4mm)
MD5601 ACT-M14XX 10.20～66.28 1.00～6.50 8.85～70.80 600 1.5 Hex(6.35mm) 4.0～6.0
MD6161 ACT-M20XX 3.06～13.26 0.30～1.30 2.66～11.50 5000 1.1 Hex(6.35mm) 2.0～4.0
MD6162 Hex(4mm)
MD6392 ACT-M21XX 10.20～45.90 1.00～4.50 8.85～39.83 1200 1.4 Hex(6.35mm) 3.0～6.0
Hex(4mm)
MD6601 ACT-M24XX 40.80～102.00 4.00～10.00 35.40～88.50 600 1.7 Hex(6.35mm) 4.0～8.0
MD6701 ACT-M27XX 71.30～153.00 7.00～15.00 61.90～132.00 300 1.9 Hex(6.35mm) 6.0～10.0
