Specifications
Brand Name :
AND
Model Number :
MD6701
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
Before T/T ; L/C
Delivery Time :
1-4 weeks
Packaging Details :
Paper Box
Name :
Machine Load Smart Screwdrivers
The power of motor :
AC 150W
Max. speed (rpm) :
300
Rated torque （N.m) :
6.5/10/15
Batch Head :
Hexagon (Hex)（6.35mm）
Description

Machine-loading Smart Screwdriver MD6701 Software support customization Own factory and patents

·Professional modular design.
·Equipped with efficient and powerful servo motor.
·Automatic screw feeding method. (Blow/Suction)
·With Safe and reliable dedicated cable and connector configurations
·Leading servo motor drive with precision reduction mechanism.
·Nice and compact structure, convenient and flexibleinstallation
·method, suitable for a variety of applications

This model works with ACT-M27XX controler and the hexgon type of screwdriver bits (6.35mm).
MD6701 is prioritied in high torque. It can achieve a torque output range of 7-15 N.m and 300 rpm at maximum.
You can see more information at the table below.


Dimensions (mm)
Custom Smart Motion Control Electric Screwdriver AC 150W MD6701

specifications

Model

Adapted

controller

Tool cableTorque output range

Maximum Speed

Weight

Applicable batch headAdapted outer diameter of screw (mm)
kgf.cmN.mlbf.in
Md2120ACT-M00XX HNA-M21XXC112X0. 20~2.350. 02~0.230. 18~2.0450000.5Tail1.0~2.0
MD2121 Hex(6.35mm)
MD2350 MD2351ACT-M01XX HNA-M23XX 1.52~9.180.15~0.901.33~7.9712000.7Tail2.0~3.0
Hex(6.35mm)
MD2460ACT-M02XX HNA-M24XX 2.00~12.230.20~1.201.77~10.6210000.7Tail2.0~4.0
MD2461 Hex(6.35mm)
MD5151ACT-M10XXC212X2.04~9.180.20~0.901.77~7.9750001.0Hex(6.35mm)1.8~3.0
MD5152 Hex(4mm)
MD5381ACT-M11XX 8.16~30.600.80~3.007.08~26.5512001.3Hex(6.35mm)2.5~5.0
MD5382 Hex(4mm)
MD5601ACT-M14XX 10.20~66.281.00~6.508.85~70.806001.5Hex(6.35mm)4.0~6.0
MD6161ACT-M20XX 3.06~13.260.30~1.302.66~11.5050001.1Hex(6.35mm)2.0~4.0
MD6162 Hex(4mm)
ACT-M21XX 10.20~45.901.00~4.508.85~39.8312001.4Hex(6.35mm)3.0~6.0
MD6392 Hex(4mm)
MD6601ACT-M24XX 40.80~102.004.00~10.0035.40~88.506001.7Hex(6.35mm)4.0~8.0
MD6701ACT-M27XX 71.30~153.007.00~15.0061.90~132.003001.9Hex(6.35mm)6.0~10.0
