P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
Specifications
Steel Number :
1.0453
Standard :
EN1092-1 Type 01
Face :
RF , FF
Material :
P265nl
Description
P265NL 1.0453 Steel WN Flange EN1092-1 Long Neck Flanges
P265NL Steel flanges (1.0453) WN Flange EN1092-1 LONG NECK FLANGES
Material Specifications
Grade
P265NL
Number
1.0453
Classification
Non-alloy low temperature quality steel
Applicable Standards
  • EN 10216-4: 2014 - Seamless steel tubes for pressure purposes. Technical delivery conditions. Non-alloy and alloy steel tubes with specified low temperature properties
  • EN 10217-4: 2002 - Welded steel tubes for pressure purposes. Electric welded non-alloy steel tubes with specified low temperature properties
  • EN 10217-6: 2002 - Welded steel tubes for pressure purposes. Submerged arc welded non-alloy steel tubes with specified low temperature properties
  • EN 10253-2: 2007 - Butt-welding pipe fittings. Non alloy and ferritic alloy steels with specific inspection requirements
Chemical Composition (%)
Element Content
C max 0.2
Si max 0.4
Mn 0.6 - 1.4
Ni max 0.3
P max 0.025
S max 0.01
Cr max 0.3
Mo max 0.08
V max 0.02
Nb max 0.01
Ti max 0.04
Al max 0.02
Cu max 0.3
Mechanical Properties
Tensile Strength (Rm)
410-570 MPa
0.2% Proof Strength (Rp0.2)
265 MPa
Elongation at Fracture (Longitudinal)
24% min
Elongation at Fracture (Transverse)
22% min
Impact Energy (KV)
Orientation -40°C -20°C +20°C
Transverse 27 J 30 J 35 J
Longitudinal 40 J 45 J 50 J
P265NL Steel 1.0453 Material WN Flange EN1092-1 Long Neck Flange for Low Temperature Quality Applications
