Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Wireless Fire Alarm Smoke Detector
Specifications
MOQ :
1000pcs
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
50K/month
Delivery Time :
10 days
Packaging Details :
color box
Brand Name :
Symank
Model Number :
JKD-624
Certification :
CE/ROHS/SGS
Place of Origin :
China
Product name :
Fire Alarm Smoke Detector
Usage :
Detect Smoke,smoke alarm,Office building,Fire protection,warehouse etc
Material :
ABS Plastic,Double Sided Glass
Warranty :
2 Year
Operating voltage :
DC3V,24VDC No-polarity,2-3A battery
Alarm volume :
85dB/(10 inch),>85dB(A) at 3 meters,≥85dB (at 3m distance)
Sensor :
Optical speed,Photoelectric/optical
Alarm current :
≥60mA,69mA
Type :
wireless smoke detector
Dimension :
105*38mm
Weight :
180g with battery
Alarm sound level :
≥85dB (3m)
Description

10 years life span,No need to worry change.

This Smoke Alarm is suitable for use in apartments, condominiums, townhouses, hospitals, day care facilities, health care facilities, boarding houses, group homes and dormitories provided a primary fire detection system already exists to meet fire detection requirements in common areas like lobbies, hallways, or porches.

Using this Smoke Alarm in common areas may not provide sufficient warning to all residents or meet local fire protection ordinances/regulations.

This Smoke Alarm alone is not a suitable substitute for complete fire detection systems in places housing many people—like apartment buildings, condominiums, hotels, motels, dormitories, hospitals, health care facilities, nursing homes, day care facilities, or group homes of any kind.


Technical Details:

Working voltage: 2*1.5V AA battery
Static current: <3uA
Alarm current: <100mA
Alarm indication: LED flashes in Red
Inspection area: 80m² ~at 6-12m installation height; 60m²~ at installation height<6m
Shell: Dust-proof, Moth-proof and Anti White light interference
User environment: temperature: -10°C~55°C ;Relative humidity:<95% without crystallization;
Alarm type : sound and light alarming
Alarming volume: >80dB (at three meter directly in front)
Sensor: photoelectric sensor
Weight: about 180g
Dimensions: 120*120*40mm
Shell protection grade: IP30



Certificates

 EN14604:2015+AC:2008
EN62368-1:2014+A11:2017
IEC62321-1:2013
EN55014-1:2017


Install&Maintainance


1.Avoid installations in places with stagnating smoke, heavy dust, heavy water mist, heavy oil mist, great humidity(95%) and high wind speed(>5m/s)

2. Insert the ready battery into the battery cabinet, notice the place of anode and cathode.

3. Choose a proper position. Normally, the center of the detection area ceiling is recommended. Fix the detector base into the chosen position Then put the detector into the base and twist to fasten it. Be sure it is fastened tightly.

Check your home: 80m² ~at 6-12m installation height;

60m²~ at installation height<6m
