M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal
Specifications
Price :
Depends on length & MOQ, welcome your inquiry
Payment Terms :
T/T
PIN Configuration :
2 Power Pins (Large) + 6 Signal Pins
Brand Name :
RITIAN
Model Series :
Power Charging Terminal Series(male&female)
Keying :
Polarized design to prevent mis-mating
MOQ :
100 PCS
Delivery Time :
5-8 days for the samples, 15-25 days for bulk
Flame Rating :
UL94-V0
Color Options :
Black housing with blue accents (as shown)
Packaging Details :
Neutral Carton or Customized Package
Compliance :
Meets industrial electrical safety standards
Place of Origin :
CHINA
Certification :
CE
Model Number :
M18-2P6S-500V20A
Gender :
Available in Male (Plug) and Female (Receptacle)
Supply Ability :
30000 PCS / Month
Mounting Type :
Panel Mount / Cable Assembly
Description

Product Overview

1. The M18 2+6 EV Backup Power Connector is a high-reliability industrial-grade circular connector designed for energy storage systems, EV backup power units, and high-voltage charging applications.

2. With a 2 power + 6 signal pin architecture, it enables simultaneous power transmission and signal communication in compact industrial environments.

3. Rated at 500V / 20A, this connector ensures stable performance in demanding electrical systems such as EV charging infrastructure, battery management systems (BMS), and industrial backup power modules.

M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal

Key Features & Benefits

  • 1. High-Power Electrical Performance
  • Supports up to 500V AC / DC systems
  • Rated current: 20A (power pins), 3A (signal pins)
  • Low contact resistance ensures minimal energy loss

2. Hybrid Power + Signal Design

  • 2 large power contacts + 6 signal terminals
  • Ideal for BMS, control signals, and communication lines
  • Reduces wiring complexity in EV systems

3. Industrial-Grade Durability

  • ≥3,000 mating cycles
  • High mechanical stability for repeated plug/unplug operations
  • Anti-vibration locking structure

4. Safety & Protection

  • UL94-V0 flame-retardant housing
  • High insulation resistance ≥100MΩ
  • Designed for harsh industrial environments

5. Compact M18 Circular Design

  • Space-saving structure for dense electrical assemblies
  • Easy panel mounting and cable integration
  • Polarized anti-misconnection design

M18 2+6 EV Backup Power Connector 500V 20A High Current Terminal

Technical Parameters

Item Specification
Series M18 2+6 Power & Signal Connector
Rated Voltage 500V AC/DC
Rated Current 20A (Power Pins), 3A (Signal Pins)
Pin Configuration 2 Power + 6 Signal
Contact Resistance ≤10mΩ
Insulation Resistance ≥100MΩ
Operating Temperature -25°C to +70°C
Mating Cycles ≥3000 cycles
Protection Rating Industrial sealed design (optional IP upgrade)
Flame Rating UL94-V0
Dimensions (approx.) Refer to technical drawing (29mm x 31mm flange, etc.)
Applications ESS, EV, Industrial Automation Equipment, UPS systems, Renewable Energy Systems
