OE-185A-2S Twin Stage Compressor | Heavy-Duty Large Displacement & Standard DN100 Port
OE-185A-2S Twin Stage Compressor | Heavy-Duty Large Displacement & Standard DN100 Port
Specifications
Brand Name :
FU PRO
Model Number :
OE-185A-2S
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
20000-420000CNY
Payment Terms :
50% deposit in advance,balance 50% before shipment
Supply Ability :
Stable bulk supply, long-term orders accepted
Delivery Time :
Standard / Custom Orders: Shipment within 15-25 working days upon receipt of advance payment.
Packaging Details :
Bubble Wrap / Stretch Wrap
Model :
OE-185A-2S Fixed-Speed Two-Stage Screw Compressor
Rated Airflow :
41.35m³/min@6Bar(g),36.41m³/min@8Bar(g),32.25m³/min@10Bar(g),27.46m³/min@13Bar(g)
Outlet :
DN100
Overall Dimension :
4600×2100×2270mm
Noise Level :
86dB(A)
Net Weight :
6800kg
Application :
Super-heavy machinery manufacturing base, full-process large coating industrial park, giant mass-production rubber & plastic industrial park
Description
OE-185A-2S Two-Stage Screw Air Compressor | Extra Large Fixed Rated Capacity & Multi Working Pressures

Product Description

OE-185A-2S fixed-speed two-stage screw air compressor delivers rated airflow:41.35m³/min@6Bar(g),36.41m³/min@8Bar(g),32.25m³/min@10Bar(g),27.46m³/min@13Bar(g). Equipped with DN100 exhaust port, overall dimension 4600×2100×2270mm, net weight 6800kg, noise level 86dB(A). Fully load tested before shipment, specially designed for super-large heavy industry base, integrated coating industrial park and full-chain rubber & plastic giant factory centralized air supply for bulk export.

Core Selling Paragraph

Four preset standard working pressures plus ultra-large fixed airflow guarantee uninterrupted extreme air consumption for all-day full-load giant production parks, while standard large-bore DN100 flange port and 86dB heavy enclosed cabinet ensure firm pipeline connection and comply with environmental noise rules for super-large industrial zones.

Technical Data Sheet





Item Specification
Model OE-185A-2S Fixed-Speed Two-Stage Screw Compressor
Rated Airflow 41.35m³/min@6Bar(g),36.41m³/min@8Bar(g),32.25m³/min@10Bar(g),27.46m³/min@13Bar(g)
Outlet DN100
Overall Dimension 4600×2100×2270mm
Noise Level 86dB(A)
Net Weight 6800kg
Application Super-heavy machinery manufacturing base, full-process large coating industrial park, giant mass-production rubber & plastic industrial park

FAQ

Q1: Suitable application?

A: Super-large heavy industrial parks with round-the-clock full-load and huge air demand.

Q2: Reducer flange available for DN100 port?

A: Custom reducing flanges optional without performance drop.

Q3: Can maintenance spare parts ship together?

A: Complete filter kits and special screw lubricant can be loaded in same export container.
