Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable
Specifications
Brand Name :
AIMLASER
Certification :
FDA
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
,T/T,Western Union,PayPal
Delivery Time :
5-10 days
Product Name :
Fiber Pluggable Laser Module
Wavelength :
450nm
CW Output Power :
3mW
Fiber :
Multimode
Fiber core :
105μm, 200μm, 400μm, UV Multimode Fiber available)
Package :
Coaxial laser diode packaging
Description

Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable

Fiber Pluggable Laser Module

AIMLASER’s pluggable fiber-coupled laser module is a compact, high-reliability light source designed for plug-and-play operation and long service life. It supports a wide wavelength range from 405nm to 980nm, with output power options from 30mW to 3500mW.

This laser adopts a coaxial packaging structure and features a detachable multimode fiber, providing excellent beam pointing stability and easy maintenance. The standard configuration includes a 105μm fiber core, 1-meter fiber length, and SMA905 connector, with optional customization for core size (105μm, 200μm, 400μm, UV fiber), fiber length, and connector types (SMA905, FC, SC, 2.5mm ferrule).

It features a multimode output beam with a spectral width of 3nm, a numerical aperture of 0.22, and a wavelength temperature coefficient of 0.05nm/°C, delivering stable optical performance under standard conditions. This makes it ideal for use in PCB imaging, CTP and LDI systems, alignment and guide light, industrial printing, as well as scientific research and education.

Fiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector CustomizableFiber Pluggable Laser Module 405–980nm 30mW 105μm Core SMA905 Connector Customizable

Features

  • Excellent beam pointing stability

  • Plug-and-play fiber interface for quick setup

  • Detachable laser module for flexible use

  • Long operational lifetime with minimal maintenance

​

Specifications

Parameter Specification
Wavelength Range 405 nm – 980 nm
Output Power 30 mW – 3500 mW (customizable)
Laser Type FP (Fabry–Perot)
Beam Mode Multimode
Spectral Width ≤ 3 nm
Wavelength Temp. Coefficient 0.05 nm/°C
Fiber Type Multimode fiber (105 μm standard; 200/400 μm & UV optional)
Numerical Aperture (NA) 0.22
Connector Type SMA905 (standard); FC, SC, 2.5mm ferrule optional
Fiber Length 1 m (standard); customizable
Package Type Coaxial package
Operating Temperature 25 °C
Pluggability Detachable fiber for plug-and-play use

Applications

  • PCB and CTP laser imaging

  • LDI (Laser Direct Imaging) systems

  • Alignment and guide light

  • Industrial printing

  • Scientific research and education

​

​Trade Terms

1) Payment: T/T, PayPal, Western Union, etc.

2) Shipment: FedEx, DHL, UPS, etc.

3) Delivery Time: 5 - 20 days.

4) Shipment Terms: FOB Xi'an, China.

Our Services

A. All products come with a one-year warranty.

B. Use original LDs from Arima, Osram, Nich, and so on to guarantee reliability.

C. Product conforms to FDA, IEC, and GB standards.

D. Strictly following ISO9001:2008 quality system.

E. Provide OEM & ODM services, support customized for your requirement.

F. Strong design and production capabilities.
