SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
Specifications
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Delivery Time :
5-8 working weeks
Packaging Details :
Standard export ply-wood case
Structure :
/
Pattern Description :
/
Mesh × Count (l/cm) :
/
Warp Diameter (mm) :
/
Weft Diameter (mm) :
/
Warp Material :
/
Air Permeability :
/
Caliper (mm) :
/
Elongation(50N/cm) :
/
Break Strength :
/
Fiber Support Index (FSI) :
/
Drainage Index (DI) :
/
Open Area :
/
Fabric Color :
/
Description
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support

The KRAFT SSB50210WC48 is a triple layer forming cloth that combines a two‑shed paper side with a ten‑shed wear side for superior sheet support and drainage. The fine mesh on the paper side promotes uniform formation, while the wear side features long floats and a 3:2 CD shute ratio (forming side to wear side). This arrangement permits the use of medium and coarse CD yarns on the wear side, boosting durability and stability. Two MD thread systems provide excellent cross‑directional stability, reducing fabric distortion. The open weave structure not only enables high dewatering rates but also allows easy showering, making this fabric a reliable choice for paper machines requiring extended running time.


Key Features
  • Medium CD yarns used on wear side for balanced durability.
  • Long float design on wear side provides exceptional wear potential.
  • Good fiber support enables uniform paper formation.


Product Parameters
Product Name Forming Fabric KRAFT SSB50210WC
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical SSB Triple Layer forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
Top Side View Bottom Side View
Application
Light Weight Kraft, Wrapping and Packaging Papers, Board Grades filler layer, under-top layer or back layer, etc
SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support SSB Triple Layer Paper Machine Forming Fabric : KRAFT SSB50210WC48-440CFM Two Shed / Ten Shed Shute Binding Design for Stable Construction & Excellent Fiber Support
