1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
Specifications
Pattern description :
5/10 Shed
Basis Weight (g/m²) :
620
CMD Yarns Top :
0.27mm 15.5 /cm PET/PA
Air Permeability :
520 CFM @ 125 Pa
Void Volume :
674 ml/m² (59.1%)
Caliper (mm) New :
1.140
Fiber Support Index :
79
Paper Side Open Area :
21.4%
CMD Yarns Bottom :
0.45mm 15.5 /cm PET/PA
Fiber Support Point :
/
Drainage Index :
24.7
Caliper (mm) Critical :
0.720
Break Strength :
≥800 N/cm
Structure :
1.5 Layer
Fabric Color :
Light Green, Light Blue, White
Brand Name :
ATMC
MOQ :
1pc
Price :
inquiry
Payment Terms :
L/C,D/A,D/P,T/T
Packaging Details :
Standard export ply-wood case
MD Yarns Top :
0.25mm 24.0 /cm PET
MD Yarns Bottom :
/
Elongation(50N/cm) :
≤0.50%
Description
5/10 Shed Weave Forming Fabric KRAFT SLA24510C - Increased Void Volume for Excellent Fiber Support and Sheet Release
The KRAFT SLA24510C is engineered with a coarse mesh, ten-shed, 1.5-layer structure that delivers greater internal void volume and enhanced drainage. This ten-shed fabric is suitable for both Fourdrinier and multi-wire machines across various paper grades, particularly where a longer service life compared to single-layer designs is a key requirement.
Key Features
  • Uniform hole size with excellent drainage
  • Good fiber support and sheet release
Product Parameters
Product Name Forming Fabric KRAFT SLA24510C
Material Polyester monofilament
Function Paper Machine
Application Light GSM Kraft Paper, Wrapping Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weight Customized
Fabric Color Customized
Product Images
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
Top Side View
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
Bottom Side View
Application
Wrapping and Packing Papers, Board Grades.
1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production 1.5-Layer Design with 5/10 Shed Weave Forming Fabric for Good Sheet Release in Kraft Paper Production
