127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
127hp 15ton Earth Excavation Machine With Four Wheel Drive
Specifications
Brand Name :
Hengte
Model Number :
HT155W
Place of Origin :
China
MOQ :
1 unit
Price :
USD68500/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200unit per month
Delivery Time :
30days
operationing weight :
15450KG
rated speed :
93/2200 (kw/rpm)
Maximum Digging Height: :
9100mm
Max Digging Radius: :
8120mm
power :
127hp
Wheelbase: :
2670mm
Maximum Digging D :
5040
Bucket capacity: :
0.63m3
Moving Type :
wheel excavator
Description

Wheel Excavator HT155W HENGTE 15ton Wheel Excavator earthmoving machinery

15ton wheel Excavator HENGTE HT155W

1. Parameter of HENGTE HT155W Wheel Excavator

a Shipping Length 7760 (mm)
b Shipping Height) 3120 (mm)
c Overall Width 2700 (mm)
d Tyre Type 9.00-20
e Radius, Swing Center to Rear End 2400 (mm)
f Wheelbase 2670 (mm)
g Whell Tread 1970 (mm)
h Min Ground Clearance 250 (mm)
i The Length of Arm 4600 (mm)
j The Length of Boom 3131(mm)

Working range:

a Max. Digging Height 9100 (mm)
b Max. Dumping Height 6650 (mm)
c Max. Digging Depth 5040 (mm)
d Max. Digging Radius 8120 (mm)

Technical parameters:

Engine Type QSB3.9-C125 Cummins
Power 93/2200 (kw/rpm)
Hydraulic System Pressure 32(MPa)
Hydraulic System Flow 2X130(L/min)
Bucket Volume 0.60 (m3)
Bucket Digging Force 85 (KN)
Arm Digging Force 53 (kN)
Gradeability 70%
Rotation Speed 13-14 (r/min)
Travel Speed 30(km/h)
Approximate Weight 15450 (kg)

Photo in Details

127hp 15ton Earth Excavation Machine With Four Wheel Drive

127hp 15ton Earth Excavation Machine With Four Wheel Drive

127hp 15ton Earth Excavation Machine With Four Wheel Drive

127hp 15ton Earth Excavation Machine With Four Wheel Drive

127hp 15ton Earth Excavation Machine With Four Wheel Drive127hp 15ton Earth Excavation Machine With Four Wheel Drive127hp 15ton Earth Excavation Machine With Four Wheel Drive127hp 15ton Earth Excavation Machine With Four Wheel Drive

127hp 15ton Earth Excavation Machine With Four Wheel Drive
