Durable Harrow Blades Rust-Proof For Precision Farming And Soil Preparation
Yucheng Xinyi Machinery Manufacturing Co., Ltd.
Product Technical Parameter
Name:65Mn Plough Plow Blade Harrow Disc Blade for Harrow Plough
Disc blade is widely used in disc plough, disc harrow on the most important wear parts. we disc blade are exported to the United States, Canada, Russia, South Africa, Southeast Asia and other countries every year, with an annual export of 1 million pieces. has more than 20 years of production experience, helping customers in various regions to open up better markets.
| Material: | 65Mn,Boron steel |
| Hardness: | HRC38-45, HRC43-48 |
| Thickness: | 3.0-12.5mm |
| Size/dimension: | 12"-44"(300mm-1120mm) |
| Edge of Disc Blade: | Round or Notched. |
| Shape: | Flat,Concave or Wavy |
| MOQ: | 100 pcs |
| Production Capacity: | 7 Million pcs annually |
| Surface treatment: | Painting |
| Colors: | Blue or black ( matt or bright), Made to your order |
| Hole Type: | Square, Round, Hexagon, Clover Leaf, Optional |
| Hole Size: | 27x27mm, 42x42mm, optional |
| Working Depth: | 200mm, 300mm |
| Working Width: | 3.4M ~ 6.2M |
| Packing: | Non-fumigation wooden case, metal case according policy of different regions |
| Feature /Characteristic: | Highest wear life due to special edge making process |
| Common Specifications of Disc |
| Dia. | Concavity | Thickness |
| mm | inch | mm | mm |
| 255 | 10 | 12 | 3 |
| 305 | 12 | 19 | 3 |
| 330 | 13 | 25 | 3 |
| 355 | 14 | 38 | 3 |
| 410 | 15 | 38~50 | 3 |
| 430 | 17 | 57 | 3,4 |
| 460 | 18 | 38~60 | 3,4 |
| 480 | 19 | 57 | 3,4 |
| 510 | 20 | 44~63 | 3,4,5 |
| 535 | 21 | 63 | 3,4,5 |
| 560 | 22 | 60~85 | 4,5,6 |
| 585 | 23 | 75~90 | 4,5.6 |
| 610 | 24 | 75~95 | 4,5,6 |
| 660 | 26 | 86~115 | 5,6,7,8 |
| 710 | 28 | 100~130 | 5,6,7,8 |
| 760 | 30 | 120~135 | 6,7,8,10,12 |
| 810 | 32 | 120~140 | 8,10,12 |
| 910 | 36 | 120-200 | 8,10,12 |
| 960 | 38 | 120-200 | 8,10,12 |
Normal packing or According to your requirement.
Safe, complete and fast delivery of goods to customers.
1,All products enjoy 12 months warranty period. The warranty period is calcualted from the date of bill of lading .
2,We provide our clients with genuine spare parts with the highest quality,exact fitness .If needs,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.
3,We can also provide training services to different users.
1.Q: Full price list for these products
A: If you need the price list for these products, please notify the product model so that I can quote you accordingly. Please understand we have a very wide product range, we don't usually offer full products price list.
2. Q: Business terms
A: Shipment time: 25-40days after your payment
Shipment: By sea
Loading port: Qingdao port, China
Destination port: ...To be advised
Payment: T/T , L/C
Warranty: 1 year
3.Q:How can I order from you?
A: Please send us your enquiry list; we will reply you within two working days.
4.Q:If the finger I look for are not in your catalogue, what should I do?
A: We can develop it according to your drawing or sample.
5. Q: Why choose Xinyi for cooperation?
A: Comparing with our competitors, we have much more advantages as follows:
1. More than 25 years in manufacturing farming machine.
2. More Professional Sales staffs to guarantee the better service.
3. More agri machines for your choice.
4. More New products into your range to avoid price competition.
5. Larger quantity production and shipment.
6. Better quality to guarantee better Credit.
7. Faster delivery time: Only 7 days.
8. More stick quality checking before shipment.
9. More reasonable after-sales service terms.
10. More famous brand: "XINYI" brand and "CE"ceitification.
11.Lower repair rate and bad review rate.
12. Have received unstinting support from the Chinese government.
If you are interested in our products, feel free to contart me.
