Specifications
Brand Name :
AFP
Model Number :
Glossy & Matte
Certification :
FDA, EN 71-3, CPSIA, REACH
Place of Origin :
Fujian, China
MOQ :
2 Tons (Mixed roll width accepted)
Price :
USD2355.00/Ton ~ USD2588.00/Ton
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
1000 Tons per month
Delivery Time :
15 - 25 working days
Packaging Details :
1-One roll one carton with plastic caps protection; 2-Tens of rolls a pallet; 3-Ten pallets a 20FCL
Material :
BOPP + EVA
Type :
Laminating Film Supplier
Softness :
Soft
Thickness :
15micron, 18micron, 20micron, 23micron, 25micron
Transparent :
Transparency
Roll Size :
350mm*3000m, 445mm*3000m, etc.
Corona Treatment :
Double sides, over 42 dynes
Paper Core :
1 inch (25.4mm), 3"(76mm)
Technology :
Multiple Extrusion
Usage :
Printed Paperboard or Paper Laminate
Description
Waterproof BOPP Thermal Lamination Film Roll
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Trustworthy Professional BOPP Thermal Roll Laminating Film Supplier

As a professional manufacturer and supplier of BOPP thermal roll laminating film, we have been trusted by clients since 2008. We produce high-quality roll laminating film using 8 high-speed co-extrusion coating lines, with a monthly capacity of 1,000 tons, ensuring fast delivery within 20 days for a 40-foot container.

Our product is used to laminate printed paper or paperboard by heating the coated EVA via roll laminator machines. The two main finishing types are Glossy (also called Bright or Shine) and Matte (also called Dull or Matt). Product data for other finishing types is available upon request.

Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Applications
  • Leaflets
  • Brochures
  • Documents
  • School paper
  • Shopping bags
  • Textbook covers
  • Cosmetics boxes
  • Sweet boxes and diaries
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Product Data Sheet
Transparent BOPP Thermal Laminating Film Roll
Specifications Model No. AFP-L18 AFP-L21 AFP-L25 AFP-L25 AFP-Y20 AFP-Y25 AFP-Y27
Type Glossy Glossy Glossy Glossy Matte Matte Matte
Thickness BOPP 12micron 12micron 12micron 15micron 12micron 15micron 15micron
EVA 6micron 9micron 13micron 10micron 8micron 10micron 12micron
TOTAL 18micron 21micron 25micron 25micron 20micron 25micron 27micron
Yield m²/kg 61.275 52.247 43.668 43.956 56.433 45.147 41.615
kg/m² 0.0163 0.0191 0.0229 0.0228 0.0177 0.0222 0.024

Customized thickness combination available (15 micron to 30 micron, glossy and matte)

Price by weight or square meter available

  • Thickness Tolerance: ±1μm (micron)
  • Roll Width: from 180mm to 1880mm
  • Roll Length: from 300m to 4000m
  • Joint: ≤1
  • Core Size: 1inch (25.4mm), 3inch (76.2mm)
  • Corona Treatment: Single or Double, ≥ 38dyne
  • Shelf Life: 9 months
  • MOQ: 2 tons (mixed width available 500mm,600mm,700mm etc.)
Operation Guidance
  • Compound Temperature: 85℃ - 105℃ (185℉ - 221℉)
  • Compound Pressure: 10-18 mpa
  • Compound Speed: 10-60m/min
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Manufacturing Process
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Raw Material Inspection
  • BOPP Film
  • EVA (TOTAL E182L, DUPONT)
Adhesion Coating
  • Symmetrical thickness
  • Strong surface tension
Quality Testing
  • Corona treatment
  • Peel strength
Splitting & Rewinding
  • Precise roll measure
  • Smooth surface
Packaging & Shipping
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Roll Body
  • Clear plastic bubble film
  • Label outside
Overlayer Carton
  • Five layers corrugated box
  • Protective plastic cap
Pallet Packaging
  • Corner protection
  • Strongly stretched
Container Loading
  • Dunnage bag used
  • No dropping
Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron Waterproof BOPP Thermal Lamination Film Roll 15micron 18micron 20micron 23micron 25micron
Download Product Data
BOPP Thermal Lamination Film Data Sheet.pdf
Download Certificates
CERTIFICATE of REACH SVHC.pdf CERTIFICATE of FDA n CPSIA.pdf CERTIFICATE of EN 71-3.pdf
