PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
Specifications
Brand Name :
AFP
Model Number :
Roll Lamination Film
Certification :
SGS, BV,
Place of Origin :
Fujian, China
MOQ :
1 Ton (1,000kgs)/Trial Order Negotiable
Price :
USD 2188.00/Ton ~ USD 2370.00/Ton
Payment Terms :
T/T, L/C, Western Union, Paypal
Supply Ability :
850 Tons per month
Delivery Time :
15 - 25 working days a 40GP
Packaging Details :
1-One roll one carton with plastic caps protection; 2-Tens of rolls a pallet; 3-Twenty pallets a 20FCL
Material :
PET + EVA
Softness :
Soft
Paper Core :
1 inch (25.4mm), 3"(76mm)
Transparency :
Transparent
Roll Size :
445mm*3000m, 630mm*4000m, 770mm*4000m
Corona Treatment :
Double sides, over 42 dynes
Thickness :
12micron, 25micron, 75micron, 125micron, 250micron etc.
Usage :
Printed Paperboard or Paper Laminate, Shopping Bag Laminate
Description
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
High Quality PET Polyester Thermal Laminating Film Roll

AfterPrinting offers high-quality PET thermal lamination film at competitive prices, serving as a reliable China supplier and business partner for packaging materials in the post-press field.

Product Specifications
Specification AFP-L18 Glossy AFP-L21 Glossy AFP-L25 Glossy AFP-L25 Glossy AFP-Y20 Matte AFP-Y25 Matte AFP-Y27 Matte
Thickness (um) PET 12 micron 12 micron 12 micron 15 micron 12 micron 15 micron 15 micron
Thickness (um) EVA 6 micron 9 micron 13 micron 10 micron 8 micron 10 micron 12 micron
TOTAL 18 micron 21 micron 25 micron 25 micron 20 micron 25 micron 27 micron
Yield m²/kg 61.275 52.247 43.668 43.956 56.433 45.147 41.615
Yield kg/m² 0.0163 0.0191 0.0229 0.0228 0.0177 0.0222 0.0240
Customization Available: Thickness combinations from 15 micron to 32 micron, both glossy and matte finishes. Pricing available by metric ton or square meter.
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
What is PET Thermal Lamination Film?

PET Thermal Laminating Film is primarily composed of PET + EVA layers combined through an extrusion coating process. The final film features PET film properties on one side and a heat-sensitive surface for dry lamination on the other.

  • Available in glossy/shine/transparent and matte/opaque classifications
  • Thickness range: 12 micron to 250 micron
  • Width options: 180mm to 1880mm
  • Length options: 150m (1 inch core, 25mm) to 4000m (3 inch core, 76mm)
Applications

PET Thermal Laminating Film is widely used for:

  • Textbook covers
  • Brochures and leaflets
  • Sweet boxes and cosmetics packaging
  • Shopping bags
  • Diaries
PET Polyester Roll Laminating Film Double Side Corona Treatment SGS Approval
How to Use PET Thermal Lamination Film

A laminating machine (hot laminator) is required to use PET thermal laminating film rolls. The process involves melting the EVA layer onto substrates like paper by passing the film over a heated roller under appropriate pressure.

Operation Guidance on Laminating Process
  1. Adjust roller pressure and temperature according to paper and ink types
  2. Conduct small trial volumes before mass lamination when changing sizes
  3. Normal process temperature: 90°C-105°C (203°F - 221°F)
  4. Ensure ink is completely dry before laminating
  5. Store materials in low-temperature, dry environments

Factors affecting lamination quality:

  • Use of metal ink
  • Ink containing excessive wax, dried oil, adhesive, or silicon additives
  • Overly thick ink application
  • Insufficient ink drying time
  • Excessively humid paper
  • Too much surface powder
Frequently Asked Questions
Packing and Shipping
  • One roll per carton
  • Tens of rolls per pallet
  • 10-12 pallets per 20ft container (approx. 13MT)
  • 20-22 pallets per 40ft container (approx. 25MT)
  • Seaports: Xiamen, Shanghai, Ningbo
  • Airbags used for pallet protection during container loading
Samples
  • Free testing samples available
  • Standard sample size: 300/400mm × 100m/200m per glossy or matte roll
  • Custom sample sizes available upon request
  • Freight costs borne by receiver, refunded against future orders
  • Prepaid shipping recommended for cost savings
Production Capacity
  • 2 coating lines operational
  • 20-day delivery for 40ft container orders
  • 350MT monthly production capacity
  • Thickness range: 15 micron to 32 micron (both glossy and matte)
  • Roll width: 180mm to 1680mm
  • Roll length: 2000m to 6000m
  • Reel inner diameter: 25.4mm (1 inch) or 76mm (3 inch)
  • Reel outer diameter: 240mm to 380mm
