22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
Specifications
Brand Name :
AFP
Model Number :
Metalized Polyester Film
Certification :
SGS
Place of Origin :
Fujian, China
MOQ :
2000KGS
Price :
USD2.79-5.5/KG
Supply Ability :
450Tons/month
Delivery Time :
20days
Packaging Details :
Carton and Pallet
Type :
Metalized Polyester Film
Thickness :
From 17micron to 25micron
Width :
180mm-1300mm
Core Diameter :
3" (76mm)
Corona treatment :
Both sides corona treated, over 42dynes
Printable :
Yes
Application :
For Lamination and Printing
Machine :
Thermal Lamination Machine
Length :
1000m-4000m
Delivery Lead :
20Days
Description
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
Product Overview

22mic Thermal Metalized Polyester Film for Paper/Paperboard creates an aluminum paper appearance when laminated with paper. This film is ideal for daily consumable packaging boxes including grocery, medicine, wine, and other product packaging.

Type Metallic/Metalized Thermal Laminating Film Base Film MPET (Offset Printing) MPET (Screen Printing)
MPET 12 micron 12 micron 12 micron 12 micron
EVA 12 micron 12 micron 12 micron 10 micron
TOTAL 24 micron 24 micron 24 micron 22 micron
Yield 35311 sqm/MT 37878 sqm/MT 35311 sqm/MT 37878 sqm/MT
Weight 0.0283 kgs/sqm 0.0264 kgs/sqm 0.0283 kgs/sqm 0.0264 kgs/sqm

Note: Customized thickness composition and colors are available.

Technical Specifications
  • Width: 200mm to 1200mm
  • Length: 2000m to 4000m
  • Tolerance: +/-1 um
  • Paper Core: 76mm (3 inch), 50.8mm (2 inch), 25.4mm (1 inch)
  • Corona Treatment: Double sides corona treatment
  • Surface Tension:
    • MPET (Offset Printing) side ≥52 dynes; EVA side ≥52 dyne
    • MPET (Screen Printing) side ≥42 dyne; EVA side ≥52 dyne
Lamination Guidance
  • Compound Temperature: 90ºC-150ºC (194ºF-302ºF)
  • Compound Pressure: 10-18 mpa
  • Compound Speed: 10-60 m/min
Color Options

Available in various metallic colors including Silver, Gold, and other custom colors. Both gloss and matte finishes available. Custom colors can be matched to Pantone standards.

22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
What is Thermal Metalized Polyester Film?

Thermal Metalized Polyester Film consists of Metalized Polyester Film and EVA Glue, with thickness ranging from 17 micron to 25 micron, primarily at 24 micron (12 MPET + 12 EVA).

  • Name: PET Metallic Thermal Laminating Film
  • Material: Super treatment Metallic PET Film + EVA
  • Color: Gold, Silver and other colors (as per Pantone)
  • Features: Strong adhesion, perfect surface tension, nice rewinding, with double sides corona treatment valued above 42 dynes
22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard

There are two types of Metalized Thermal Lamination Film: chemical and corona treated metalized thermal lamination film for offset printing, and corona treated metalized thermal lamination film.

22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard

Applications of PET Metalized Thermal Lamination Film Worldwide

  • Europe: Medicine Box packing
  • Middle East: Cake Tray
  • Mexico: Cosmetic Box Packaging
  • Southeast Asia: Cardboard for packing
  • Polyester Metallized Thermal Lamination Film Supplier Latin Americans
  • PET Metalized Lamination Roll Nigeria
Packaging and Shipping
  • One roll per carton
  • Tens of rolls per pallet
  • 10-12 pallets per 20ft container (approximately 13 MT)
  • 20-22 pallets per 40ft container (approximately 25 MT)
  • Seaports: Xiamen, Shanghai, Ningbo

Airbags are used for protecting the pallets from collision during container loading.

22mic Metalized Polyester Film 180mm-1300mm Width For Paper / Paperboard
Frequently Asked Questions (FAQ)
How Can I Get a Sample?

Samples for testing are free. The normal sample dimension is 300mm × 100m. Customized width and length samples are available upon request.

What Is Minimum Order Quantity?

The MOQ is 2 tons. Pricing is primarily determined by order quantity.

What About the Price?

Price is negotiable according to quantity and color requirements. For 2 tons: FOB USD 3.2-5.5/KG. For 20ft container: FOB USD 2.79-5.3/KG.

What About the Payment Terms?

30% deposit and 70% balance. We accept T/T and L/C payment terms. Supported currencies: USD, CNY, CAD, HKD, etc.

How About the Delivery Time?

Normal delivery lead time: 25 days. Special delivery for 40ft container: 20 days.

How About the After-Sale Service?

6-month warranty. In case of any quality problems, equivalent compensation will be provided.
