Pepperl+Fuchs KFU8-UFC-1.D | 1-Channel Frequency to Analog Converter
Pepperl+Fuchs KFU8-UFC-1.D | 1-Channel Frequency to Analog Converter
Specifications
Brand Name :
Pepperl+Fuchs
Model Number :
KFU8-UFC-1.D
Certification :
ATEX
Place of Origin :
SG
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Pepperl+Fuchs KFU8-UFC-1.D | 1-Channel Frequency to Analog Converter

Pepperl+Fuchs KFU8-UFC-1.D signal conditioner. Converts 1 mHz–12 kHz input to 0/4–20 mA, with relay outputs, SIL 2, 20–253 V AC/DC supply.

Product Overview

The Pepperl+Fuchs KFU8-UFC-1.D​ is a 1-channel universal frequency converter and signal conditioner​ designed for process and factory automation. It converts digital pulse signals (from sensors or contacts) into a proportional 0/4–20 mA analog output​ and provides configurable relay and transistor switching outputs. With a wide 20–90 V DC / 48–253 V AC​ power range and SIL 2​ capability, it serves as a versatile interface for frequency monitoring, speed measurement, and trip alarm applications.

Technical Specifications (Electrical & Functional)

Parameter

Specification

Manufacturer / Series​

Pepperl+Fuchs / KFU8-UFC

Model​

KFU8-UFC-1.D

Input Type​

Digital (2-/3-wire sensor, NAMUR, dry contact)

Input Frequency Range​

0.001 Hz – 12 kHz (1 mHz – 12 kHz)

Analog Output​

0/4 mA – 20 mA (programmable)

Switching Outputs​

2 Relay (potential-free) + 1 Transistor

Power Supply Range​

20 – 90 V DC / 48 – 253 V AC (50/60 Hz)

Line Fault Detection (LFD)​

Yes (NAMUR NE44)

Functional Safety (SIL)​

SIL 2 (IEC 61508)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Housing Dimensions (WxHxD)​

40 x 100 x 115 mm

Mounting​

DIN Rail (TS-35/7.5 or TS-35/15)

Connection​

Screw Terminals

Degree of Protection​

IP20

Operating Temperature​

-20 °C to +60 °C

Isolation​

Reinforced insulation between circuits

Configuration​

Keypad or PACTware (DTM)

Key Features

  • Universal Input:​ Accepts 2-/3-wire DC sensors, NAMUR sensors, and dry contacts.

  • Wide Frequency Range:​ Measures from very slow pulses (1 mHz) up to 12 kHz.

  • Flexible Outputs:​ Combines an analog current output with two relay alarms and one transistor output.

  • Process Safety:​ Supports SIL 2 applications with integrated line fault detection.

Applications

  • Speed monitoring of motors and conveyors

  • Flow rate measurement from pulse-output sensors

  • Frequency-to-analog signal conversion in control cabinets

  • Trip value monitoring and alarm signaling
