6EP1336-3BA10 | SITOP PSU100S 24V DC 20A DIN Rail PSU, 120/230V AC Input, Adjustable, IP20
6EP1336-3BA10 | SITOP PSU100S 24V DC 20A DIN Rail PSU, 120/230V AC Input, Adjustable, IP20
6EP1336-3BA10 | SITOP PSU100S 24V DC 20A DIN Rail PSU, 120/230V AC Input, Adjustable, IP20
6EP1336-3BA10 | SITOP PSU100S 24V DC 20A DIN Rail PSU, 120/230V AC Input, Adjustable, IP20
Specifications
Payment Terms :
T/T,XT,ALIPAY
Power Supply :
1
MOQ :
1
Certification :
ATEX
Delivery Time :
Negotiable
Certifications :
S
Supply Ability :
100pcs per month
Packaging Details :
carton
Electrical Rating :
G
Model Number :
6EP1 336-3BA10
Price :
Negotiable
Ambient Temperature :
-
Description
6EP1336-3BA10 | SITOP PSU100S 24V DC 20A DIN Rail PSU, 120/230V AC Input, Adjustable, IP20
6EP1336-3BA10 SITOP PSU100S switched-mode DIN rail power supply — 24 V DC 20 A (480 W), 1-phase 85–264 V AC auto-range input, adjustable 22.8–28 V, DC OK contact, screw terminals.

Product Overview

6EP1336-3BA10​ (catalog shorthand: 6EP1336-3BA10, often typed with space as 6EP1 336-3BA10) is a SITOP PSU100S single-phase switched-mode power supply​ delivering 24 V DC at 20 A (480 W nominal output). It features wide-range input (85–132 V AC / 170–264 V AC, auto-select 50/60 Hz), an adjustable output voltage of 22.8–28 V DC​ via front potentiometer, and provides 120% continuous overload capability up to 45 °C​ plus 150% power boost for 5 s. The unit mounts on a standard 35 mm DIN rail, uses screw-type terminals​ for input/output/PE, includes a DC OK green LED and floating N/O contact​ for remote monitoring, and is convection-cooled (no fan). Compatible with SITOP buffer, redundancy (RED1200), and DC-UPS extension modules.

Technical Specifications (Input & Output)

Parameter
Specification
Order Number​
6EP1336-3BA10​ (SITOP PSU100S 24 V / 20 A)
Input Voltage (Rated)​
1 × AC 120 V / 230 V (50/60 Hz), auto-ranging​
Input Voltage Range​
AC 85–132 V / 170–264 V
Nominal Input Current​
~4.2 A @ 230 V AC / ~8.5 A @ 120 V AC (full load)
Output Voltage (Rated)​
DC 24 V​ (adjustable 22.8–28 V via front pot)
Rated Output Current​
20 A​ @ 24 V DC (480 W)
Overload Capability​
120% continuous (≤45 °C); 150% for 5 s (start-up surge)
Ripple & Noise (typ.)​
≤ 150 mV pk-pk
Efficiency (typ. @ 230 V)​
≈ 91 %​
Power Loss (typ. @ full load)​
≈ 45 W

Technical Specifications (Mechanical & Environmental)

Parameter
Specification
Number of Outputs​
1 (floating, SELV)
Terminals​
Screw-type: L/N/PE (input), +/− (output), signalling contact (2×) — 0.5–2.5 mm²
Mounting​
35 mm DIN Rail (EN 60715 / TS 35)​ — snap-on
Dimensions (H × W × D)​
125 × 110 × 120 mm​ (SITOP PSU100S 20A wider than 5A/10A version)
Weight (Approx.)​
1.35 kg
Degree of Protection​
IP20​ (installed in enclosure)
Operating Temp. Range​
-25 … +70 °C​ (derating 3%/K above 60 °C)
Signalling​
Green LED (DC OK) + floating N/O relay contact (30 V DC / 1 A, 60 V DC / 0.3 A)
MTBF @ 40 °C​
≈ 1,200,000 h
Certifications​
CE, cULus (UL 508 / CSA C22.2 No.107.1), GL, IEC 60950-1 / EN 50178, Class I Div 2
EMC Emission​
EN 55022 Class B (residential & industrial)

Key Features

  • High-Current 20 A in Compact Footprint (110 mm wide):​ Delivers 480 W — sufficient for medium-sized control panels with multiple PLCs, I/O, and field devices.
  • 120% Continuous Overload + 150% Boost:​ Handles inrush of capacitive loads or multiple simultaneous startups without tripping.
  • Adjustable Output (22.8–28 V):​ Compensates for voltage drop on long DC feeder runs to remote I/O or field devices.
  • DC OK Signal Contact + LED:​ Easy integration into PLC/machine fault monitoring — detects output failure or pre-alarm condition.
  • SITOP Extension Ready:​ Snap-on buffer module (BUFFER MODULE 24V/40A), redundancy (RED1200 20A/40A), or DC-UPS mount directly beside it.

Typical Applications

  • Main Control Panel 24 V DC Supply:​ Powers S7-1200/1500 PLCs, ET 200 I/O racks, HMI panels, sensors, and small DC actuators in machine control cabinets.
  • Packaging / Converting / OEM Machinery:​ Single supply for entire machine's 24 V DC loads — compact width preserves DIN rail space for breakers & terminals.
  • Process Skid Power:​ Provides stabilized 24 V DC for analyzers, solenoid valve manifolds, and local I/O on modular process units.
  • Retrofit / Panel Upgrade:​ Replaces linear supplies or lower-efficiency SMPS — same DIN footprint with better overload behavior and diagnostics.
