Specifications
Brand Name :
Firepower
Model Number :
MFOG-091A
Place of Origin :
China
MOQ :
1
Price :
1350$
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
500/month
Delivery Time :
1 week
Packaging Details :
Sponge + Carton
Range :
±300(°/s
Zero-bias stability( (10s, 1σ) :
≤0.5°/h
Angular random walk :
≤0.02°/h
3dB Bandwidth :
≥300Hz
Zero-bias repeatability( (1σ) :
≤0.5°/h
Scale factor nonlinearity :
≤500ppm
Dimension :
φ40X20mm
Power Consumption :
≤1.5W
Description

Miniature Micro-Nano Fiber Optic Gyroscope Fizoptika VG091 FOG Sensor Manufacturer

  • Product Description

MFOG-091A Micro-Nano Fiber Optic Gyroscope is a high-precision angular rate sensor integrating advanced photonics, precision mechanics, and embedded electronics. Based on the Sagnac effect, this system utilizes integrated micro-nano fiber devices to detect, process, and feedback phase differences generated by counter-propagating light beams, enabling real-time inertial measurement.


The product is mainly composed of the following components:

A) an optical path assembly;

B) Detection and control signal circuit board;

C) Optical fiber ring skeleton, shell and other structural parts

  • Main performance parameters

Serial number

Project

Performance indicators

1

Range (°/s)

±300

2

Scale factor

7±0.7mv/o/s

3

Scale factor nonlinearity (ppm)

≤1000

4

Zero-bias stability (10s, 1σ, °/H)

≤2

5

Zero-bias repeatability (1σ, °/H)

≤2

6

Angular random walk (°/H 1/2 )

≤0.04

7

Zero bias (°/s)

≤0.05

8

Bandwidth 3dB Band Width (Hz)

≥450

9

Power supply (V)

5+0.15

10

Power Consumption (W)

≤0.7

11

Dimension (mm)

φ24X51.6



  • Outline Drawing

Miniature Micro-Nano Fiber Optic Gyroscope Fizoptika VG091 FOG Sensor Manufacturer

Miniature Micro-Nano Fiber Optic Gyroscope Fizoptika VG091 FOG Sensor Manufacturer
