Specifications
Brand Name :
Firepower
Model Number :
F70A
Certification :
CE
Place of Origin :
Shenzhzen, China
MOQ :
1 pcs
Price :
US$3,150.00~3,250.00
Payment Terms :
T/T
Supply Ability :
500 pcs per month
Delivery Time :
1 week for sample
Packaging Details :
Sponge and box
Measuring range :
±400~±800°/s
Zero bias stability :
≤0.05°/h, 10s
Zero bias repeatability :
≤0.05°/h
Random walk coefficient :
≤0.005°/√h
Scale factor nonlinearity :
≤50ppm
Scale factor repeatability :
≤50ppm
Scale factor asymmetry :
≤50ppm
Start time :
≤1s
Bandwidth :
500Hz
Power supply :
±5±0.15V
Power :
≤6W
Operating temperature :
-40~+70°C
Storage temperature :
-55~+85°C
Vibration :
20~2000Hz, 0.06g²/Hz
Impact :
30g, 11ms
Baud rate :
921600 (Customizable) bps
Output mode :
RS-422
Connector :
J30J-15TJL/(Customizable)
Overall dimensions :
70mm*70mm*30mm
Installation :
62mm*62mm
Description

Basic Info.

Model NO.
F70
Measuring Shaft Quantities
Single
Accuracy Grade
0.05deg/H
IP Rating
IP67
Certification
CE
Customized
Customized
Measuring Range
800deg/S
Bias Stability
0.05deg/H
Random Walk Coefficient
0.005deg/H
Power Supply
5V
Baud Rate
115200~921600Hz
Transport Package
Sponge and Box
Specification
70mm× 70mm× 32mm
HS Code
9031809090
Production Capacity
500/Month

Product Description

High Bandwidth Fiber Optic High Accuracy Gyroscope Short Activation Time

Fiber optic gyroscope is a kind of fiber sensor sensitive to angular rate. Its basic working principle is to use the Sagnac effect: In a ring interferometer, the light wave emitted by the light source is divided into two by the beam splitter, and the two beams of light will be along the forward and backward directions respectively. Move counterclockwise and return to the beam splitter

Product structure and features
The gyroscope structure adopts a typical optical fiber ring structure design scheme, and from the miniaturization integrated design, structural stability (resistance to shock and vibration), anti-resonance, structural symmetry, ease of installation and thermal design (temperature Characteristics) and other aspects were considered, and the existing structure of the gyro was optimized and designed.

main gyro parameters
Non-linearity scale factor: ≤50ppm (1σ)
Scale factor asymmetry: ≤50ppm (1σ)
Scale factor repeatability: ≤50ppm (1σ)
Dynamic range: ±300°/s
Zero bias stability: ≤0.05°/h (1σ)
Zero bias repeatability: ≤0.05°/h (1σ)
Random walk coefficient: ≤0.005°/√h
Bandwidth: ≥200Hz
Weight: ≤250g

Interface

Node number

Definition

Remark

1

+5V

+5V power input

2

+5V

+5V power input

3

-5V

-5V power input

4

-5V

-5V power input

5

±5VGND

Power ground (Note: must not be connected to the gyro shell)

6

±5VGND

Power ground (Note: must not be connected to the gyro shell)

7

T+

Gyro output signal+

18

T-

Gyro output signal-

the remaining

Disable
