Tamagawa Brushless Resolvers Smartsyn Hollow Shaft Encoder TS2651N181E78
Tamagawa Brushless Resolvers Smartsyn Hollow Shaft Encoder TS2651N181E78
Tamagawa Brushless Resolvers Smartsyn Hollow Shaft Encoder TS2651N181E78
Tamagawa Brushless Resolvers Smartsyn Hollow Shaft Encoder TS2651N181E78
Specifications
Brand Name :
Tamagawa
Model Number :
TS2651N181E78
Place of Origin :
Japan
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
500pcs/month
Delivery Time :
3 working days
Packaging Details :
original package
Condition :
original brand new
Warranty :
one year
Shipping way :
DHL FedEx express
Application :
Automation Industries, oil, gas, chemical industries
Certificate :
CE ISO TUV
Description

Brushless resolvers (Smartsyn)TS2651N181E78

Hollow snaft Type

Rotation angle sensor with excellent environmental resistance performance Brushless resolver.

Specifications　(Hollow Shaft types)


Size 21
Model TS2641N11E64
Type 1X-BRX
Primary R1-R2(Rotor)
Input voltage AC7 Vrms 10 kHz
Transformation ratio [K] 0.5±5 %
Electrical error (Accuracy) ±10' Max
Residual voltage 20 m Vrms Max
Phase shift -5 ° Nom
Input impedance Zro 190Ω
Output impedance Zso 300Ω Nom
Zss 270Ω Nom
Allowable rotation speed 5,000 min-1{rpm}
Operating temperature range -10℃ to +100℃
Dielectric strength AC500 Vrms 1 min
Insulation resistance 100 MΩ Min
Mass 0.3 kg Nom
Output voltage equation +type
Accessory M3 Hexagon socket set screw × 2 pieses

※Nom:Nominal value
　REF : Reference value


Outline(Hollow Shaft types)
