Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Specifications
Brand Name :
Tamagawa
Model Number :
TS5246N160
Place of Origin :
Japan
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
500pcs/month
Delivery Time :
3 working days
Packaging Details :
original package
Condition :
original brand new
Warranty :
one year
Shipping way :
DHL FedEx express
Application :
Automation Industries, oil, gas, chemical industries
Certificate :
CE ISO TUV
Description

Tamagawa Hollow Shaft Type Resolvers Rotary Encoders Incremental Encoders TS5246N160

A type that outputs a pulse train according to the rotational displacement of the shaft.

Hollow shaft Type

Model No. TS52□□N3□□ TS52□□N5□□ TS52□□N4□□
Appearance Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders Incremental Tamagawa Encoder TS5246N160 Hollow Shaft Type Resolvers Rotary Encoders
Series OIH35 OIH48 OIH60
Outside Diameter Φ35 mm Φ48 mm Φ60 mm
Moter Shaft Diameter Φ6 mm Φ8 mm Φ20 mm
Resolution 500 to 6,000 C/T 1,000 to 12,000 C/T 1,000 to 8,192 C/T
Output Phase A,B,Z,U,V,W Phase
Supply Voltage DC +5 V
Consumption Current
(NOTE1)		 200 mA Max
Output Form Line Driver
Maximum Response Frequency 200 kHz
Starting Torque 5.9×10-3 N⋅m
(60 gf⋅cm Max)		 9.8×10-3 N⋅m
(100 gf⋅cm Max)
Moment of Inertia 1.0×10-6 kg･m2 Max
(10 g･cm2 Max)		 6.5×10-6 kg･m2 Max
(65 g･cm2 Max)
Maximun Allowable Rotation 6,000 min-1(rpm)
Allowable Shaft
Load
(NOTE2)		 Radial Mounting Tolerance
　Radial　0.05 mm TIR Max
　Axial　0.2 mm Max
Shaft Inclination　0.1°Max
Axial
Mass
(Excluding Cable)		 0.2 kg Max 0.3 kg Max 0.5 kg Max
Protective Structure
(NOTE3)		 IP40
(Electronic Circuits Disclosed)		 IP40
Operating Temp. Range -20 to +85 °C
Vibration　(NOTE4) 49 m/s2 (5G)
Shock　(NOTE5) 490 m/s2 (50 G) 980 m/s2 (100 G)
  • NOTE 1) Consumption Current: Specified value for an output circuit with no load.
  • NOTE 2) Specified value for the Allowable Shaft Load. Usage to within 20% of the specified value is recommended on actual use.
  • NOTE 3) Regarding special specifications for the Protective Structure, please consult us.
  • NOTE 4) Vibration: Value which satisfies the conditions of 2 hours each for axes X, Y and Z, for a total of 6 hours.
  • NOTE 5) Shock: Value which satisfies the conditions of 3 times each for axes X, Y and Z, for a total of 18 times.
