Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Specifications
Brand Name :
Panasonic
Model Number :
MHMF042L1U2M
Place of Origin :
Japan
MOQ :
1
Price :
price negotiation
Payment Terms :
T/T,Western Union
Supply Ability :
100pcs/month
Delivery Time :
3 working days
Packaging Details :
original package cover with good quality carton case
Shipping way :
DHL FedEx express
Application :
Automation Industries, oil, gas, chemical industries
Certificate :
CE ISO TUV
Description
Panasonic MHMF042L1U2M MINAS A6 Servo Motor 400W 200V 3000rpm
Panasonic MHMF042L1U2M MINAS A6 High Inertia Servo Motor | 400W, 200V

The Panasonic MHMF042L1U2M is a high-precision AC brushless servo motor from the flagship MINAS A6 series. Delivering a rated output of 400W (0.4kW), this motor is specifically engineered with a High Inertia rotor to provide superior control and stability in applications with high load-to-rotor inertia ratios. Featuring an industry-leading 23-bit absolute encoder and a compact frame, the MHMF042L1U2M is the ideal solution for automated machinery requiring smooth motion and high positioning accuracy.
Key Performance Advantages
  • High Inertia for Load Stability: Optimized to handle larger mechanical loads with minimal vibration, ensuring stable operation and reduced tuning time in complex systems.
  • Ultra-High 23-bit Resolution: Equipped with a 23-bit absolute/incremental encoder (8,388,608 pulses/rev) for exceptionally smooth rotation and sub-micron positioning precision.
  • Advanced A6 Response: Features a 3.2 kHz frequency response bandwidth, enabling instantaneous command tracking and significantly shorter settling times.
  • Compact & Efficient Design: Part of the A6 small-capacity lineup, offering a high power-to-weight ratio to maximize machine space efficiency.
  • IP65 Environmental Protection: Ruggedized enclosure with a durable oil seal, designed for reliable operation in industrial environments with dust or moisture.
Technical Specifications (Quick Reference)
Key Parameter Specification
Manufacturer Panasonic
Model Number MHMF042L1U2M
Series MINAS A6 (Small Capacity)
Rated Output 400 W (0.4 kW)
Rated Torque 1.3 N*m
Peak Stall Torque 3.8 N*m
Rated Speed 3000 rpm
Maximum Speed 6500 rpm
Input Voltage 200 VAC
Encoder Type 23-bit Absolute/Incremental
Inertia Type High Inertia
MHMF042L1U2M Part Number Breakdown
For technical compatibility and replacement accuracy, use this breakdown:
  • MHMF: High Inertia Type (Small Capacity A6 Series)
  • 04: 400W Rated Power Output
  • 2: 200V AC Input Voltage
  • L: 23-bit Absolute/Incremental Encoder
  • 1: Standard Design Sequence
  • U2M: Specific technical suffix for the shaft end configuration, lead wire design, and hardware variant
Targeted Industrial Applications
The stability and precision of the MHMF042L1U2M make it ideal for:
  • Precision CNC Machinery: Feed axes for milling, lathes, and high-accuracy drilling
  • Electronic Component Assembly: SMT pick-and-place and high-speed bonding
  • Medical Equipment: Precise positioning for diagnostic and surgical robotics
  • Packaging Systems: Accurate labeling, filling, and conveyor synchronization
