Specifications
MOQ :
1
Brand Name :
SMX
Model Number :
MX-X20000U
Certification :
ISO,CE
Place of Origin :
China
Payment Terms :
T/T,Western Union
Supply Ability :
20000pcs/monthly
Delivery Time :
7-20days
Packaging Details :
Carton
Birghtness :
20000 lumen
Display Technology :
Liquid Crystal Display
Native Resolution :
WUXGA (1920 x 1200)
Inputs :
HDMI, VGA, USB, Ethernet
Light Source Lifespan :
20000-30000 hours
Len Shift :
V：±65%， H: ±25%
Display Panel :
3x1.0” with MLA
Screen Size :
50-500 inch
Connectivity :
HDMI, VGA, USB, Ethernet
Lan Control :
Yes
Applictaion :
3D Mapping
Description


High-Brightness 20,000 Lumen Laser Projector for Professional 3D Projection Mapping


SMX MX-X20000U 20000 lumen projectors are commonly used in higher education auditoriums, outdoor 3d mapping, and large-scale visitor attractions such as art galleries and museums.


Featuring a laser light source for up to 20,000 hours of use with no noticeable decline in image brightness over time.


A fleet of optional lenses is available for the models, allowing you to achieve your desired image size regardless of the environment.


Specification


Model

Model# MX-X20000U
Brightness(Lumen) 20,000
Overall Spec
Panel Display Panel 3x1.0"
Display Technology Liquid Crystal Display
Native Resolution WUXGA (1920 x 1200)
Laser Lifetime Normal mode 20000hrs
ECO mode 30000hrs
Projection Lens
(STD)		 Len Model MX-EG12ZLM(More lens pls check the len sheet)
Zoom/Focus Motorized
Throw Ratio (16:10) 1.24-2.01 @100inch
F 1.8-2.24
f 27.7-44.3mm
Zoom Ratio 1.62
Screen size 60-500 inch
Lens Shift V ±65%
Lens Shift H ±25%
CR Contrast Ratio(Min) 3,000,000:1
Noise Noise(dB) Full:46db / Normal:44db / Eco1:43db / Eco2:42db
Uniformity Uniformity TYP:90%
AR Aspect Ratio Native:16:10
Compatible: 4:3/16:9/normal/16:6
Terminal(I/O port)
Input VGA *1
HDMI 1.4(IN) *2
USB-A *1
USB-B *1(Display)
RJ45 *1(Display)
DVI-D *1
HD BaseT *1
Audio in(mini jack,3.5mm) *1 (VGA/DVI-D share)
DMX512 *1
Output HDMI 1.4(OUT) *1
Audio out (mini-jack,3.5mm) *1
Control RS232C (Input) *1
RS232C (Output) *1
Wired Remote(IN) *1
Wired Remote(OUT) *1
General Spec
Audio Speaker N/A
Temp.&Humidity Operating Temp. 0 to 50°C
Operating Thumidity. 20%-80%
Store Temp. -10 to 50°C
Store Humidity. 20%-80%
Other Functions
Keystone Keystone Correction V: ±30°
H:±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
Grid ImageTune correction
LAN Control LAN Control-RoomView (Crestron) Yes
LAN Control-AMX Discovery Yes
LAN Control-PJ Link Yes
Dimension&Weight( not including len)
　 Product Size (WxHxD mm) 599X240.2X493.8
Net. Weight (KG) 28.9Kg
Packaging (WxHxD mm) 745**370*630
Gross. Weight (KG) 34Kg
Package Carton
Accessory
　 Manual Languages Chinese, English
Standard Accessaries Power cord (3m, Black), Remote control
