Specifications
Brand Name :
SMX
Model Number :
MX-VL720U
Certification :
CE&ISO
MOQ :
1
Price :
1980
Payment Terms :
T/T,Western Union
Supply Ability :
10000/pcs per month
Delivery Time :
7-8 working days
Packaging Details :
Packaging Box Dimensions (WxDxH mm):510 (W)*498(D)*260(H)
Model :
MX-VL720U
Brightness :
7200 lumen
Display Panel :
3x0.64” with MLA
Display Technology :
Liquid Crystal Display
Native Resolution :
WUXGA (1920 x 1200)
Light source Life time :
FullNormal/Normal Model:20000H;ECO1 Mode:30000H
Throw Ratio :
1.2(wide)-2.0(tele)
Lens Shift :
V:＋60%～0%、 H:±29%
Contrast Ratio (FOFO) :
5000000:1
Keyston Correction (Lens@center) :
V: ±30° H：±30° Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction Grid image tune
Computer Signal Input :
VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Description

HD Laser Projector: High-Definition Picture Quality at Your Fingertips

Whether you're a home theater enthusiast or a business professional, a laser projector is an excellent choice for your next projection needs. With their advanced technology, impressive image quality, and versatility, these devices offer a superior projection experience that is sure to impress.
A laser projector is a cutting-edge device that uses lasers to project high-quality images or videos onto a screen or other flat surface. Unlike traditional projectors that use bulbs or lamps to create the image, a laser projector uses a powerful laser beam to produce stunning, crystal-clear visuals.


Professional-grade 7200 Lumens Laser Projector For Immersive Projection 360 Mapping System

1. WUXGA resolution
WUXGA Resolution (1920×1200 pixels) delivers high-definition video imagery. This technology ensures vibrant details are preserved even during large-screen projections, offering users an energized visual experience that brings content to life with exceptional clarity and color accuracy.
(For example, projecting a 150-inch image, WUXGA maintains precise texture rendering in scenes like forest landscapes or city skylines, avoiding pixelation common in lower resolutions like 1080p.)

Professional-grade 7200 Lumens Laser Projector For Immersive Projection 360 Mapping System


2. 500,000:1 high contrast
Reduce ambient light interference to ensure delicate, razor- projection quality, enabling crisp text and graphics with professional-grade clarity.
(Example: In a conference room with ceiling lights, this technology maintains precise spreadsheet legibility and architectural renders, eliminating the "washed-out" effect common in standard projectors.)

Professional-grade 7200 Lumens Laser Projector For Immersive Projection 360 Mapping System


Brightness

Brightness

(Lumens)

7200

Overall Spec

　

　

Panel

Display Panel

3x0.64” with MLA

Display Technology

Liquid Crystal Display

Native Resolution

WUXGA (1920 x 1200)

Light source

Life time

FullNormal/Normal Model

20000hrs

ECO1 Mode

30000hrs

ECO2 Mode

30000hrs

Projection

Lens

Lens Vendor

RICOH Lens

F

1.5~2.08

f

17.2~27.7mm

Zoom/Focus

Manual

Throw Ratio

1.2(wide)-2.0(tele)

Zoom Ratio

1.6

Screen Size

30-300 inch

Lens Shift

V:＋60%～0%,

H:±29%

CR

Contrast Ratio

(FOFO)

5000000:1

Noise

Noise(dB)

38dB(Normal)

30dB(ECO1)

28dB(ECO2)

Uniformity

Uniformity(Actual Min)

-JISX6911

80%

AR

Aspect Ratio

Native:16:10

Compatible: 4:3/16:9

Terminal(I/O port)

　

　

Input

VGA

*1

HDMI 1.4B(IN)

*2

USB-A

*1

USB-B

*1(Display)

RJ45

*1(Display)

DVI-D

N/A

HD BaseT

*1(Optional)

HD-SDI(3G-SDI)

N/A

Video

N/A

Audio in

(mini jack,3.5mm)

*1

Output

VGA

*1

HDMI 1.4B(OUT)

N/A

Audio out

(mini-jack,3.5mm)

*1

Control

RS232

*1

RJ45

*1 (Control)

USB-B

*1 (For upgrade)

Wired Remote(IN)

N/A

Wired Remote(OUT)

N/A

General Spec

　

　

Audio

Speaker

16W*1

Dust filter

W/Filter

Filter Life time

8000h

Power

Consumption

Power Requeirements

100~240V@ 50/60Hz

Power Consumption

(Normal) (Max)

360

Power Consumption

(ECO1) (Max)

280

Power Consumption

(ECO2) (Max)

230

ECO Standby Mode

Power Consumption

<0.5W

Temp.&Humidity

Operation Temp.

0 to 40°C

Operation Thumidity.

20-85%

Store Temp.

-10 to 50°C

High Altitude

0~3000m

Other Functions

　

　

Keystone

Keyston Correction

(Lens@center)

V: ±30°

H:±30°

Pincushion/Barrel Correction

6 Corner Geometry correction

4 Corner Correction

Grid image tune

OSD

Languages

26 languages:

English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi

LAN Control

LAN Control-RoomView

(Crestron)

Yes

LAN Control-

AMX Discovery

Yes

LAN Control-

PJ Link

Yes

Scanning

Frequency

H-Synch Range

15~100KHz

V-Synch Range

24~85Hz

Display

Resolution

Computer Signal Input

VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz

Video Signal Input

480i, 480p, 576i, 576p, 720p, 1080i and 1080p

SW setting

Auto Setup

INPUT SEARCH,AUTO PC,Auto Keystone

Blank

Yes

Suspend

Yes(5miniutes no singnal as default)

Picture Model

Dynamic, Standard, Cinema,

Colorboard, sim-DICOM ,Blackboard(Green)

Cooling Time

0s,normal,30s

Closed Caption

N/A

Auto Ceiling

Yes

D-Zoom

1~33

Dimension&Weight

　

　

　

MAX Dimensions

(WxDxH mm)

405 (W)*358(D)*137(H)

Net Weight

(KG)

~7.9

Packaging Box Dimensions

(WxDxH mm)

510 (W)*498(D)*260(H)

Gross.Weight

(KG)

~10.4

Accessory

　

　

　

Manual Languages

Chinese,English

Standard Accessaries

Power cord(EU) /power cord(Ja)

Remote control&RC Battery


Some applications
