Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet
Specifications
Brand Name :
TSING SHAN
Model Number :
625
Certification :
ISO SGS MTC
Place of Origin :
China
MOQ :
10KGS
Price :
10-31.5 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
7 Days
Packaging Details :
Export Packing
Usage :
Battery Pack Welding Nickel Strip
Ultimate Strength :
350-620
Advantage :
Strong conductivity
Pecifications :
Complete
Transport Package :
Standard Export Package
Porosity :
>96%
Stock Size :
0.3mm*25mm
Composition :
Primarily Nickel with varying amounts of Chromium, Iron, Copper, Molybdenum, and other elements
Loading Port :
Shanghai Port
Corrosionresistance :
High resistance to oxidation and corrosion in harsh environments
Products :
Hastelloy C-22 round bar
Feature :
high resistance
Model No :
ASTM B 444, ASTM B 829, ASME SB444,
Length :
custom any length as request
Applications :
Used in aerospace, chemical processing, power generation, and marine industries
Description

Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet

roperty Details
Alloy Name INCONEL 625 / UNS N06625
Type Nickel-Chromium-Molybdenum Alloy
Key Characteristics - Excellent oxidation and corrosion resistance in high-temperature environments
- Outstanding fatigue and thermal-fatigue strength
- Excellent weldability and formability
- Good resistance to pitting, crevice corrosion, and stress corrosion cracking
Applications - Aerospace: Jet engine components, including turbine blades and seals
- Power Generation: Gas turbines, industrial turbines, and heat exchangers
- Chemical Processing: Equipment exposed to aggressive chemicals, including heat exchangers and reactors
- Marine: Seawater applications, such as marine exhaust systems and components
Chemical Composition - Nickel (Ni): 58-63%
- Chromium (Cr): 20-23%
- Molybdenum (Mo): 8-10%
- Iron (Fe): Balance
- Niobium (Nb): 3.15-4.15%
- Titanium (Ti): 0.4-1.0%
- Aluminum (Al): 0.4%
- Carbon (C): ≤0.10%
- Silicon (Si): ≤0.5%
- Manganese (Mn): ≤1.0%
Standards - ASTM B443, ASTM B574, and others
Key Benefits - Excellent resistance to oxidation, corrosion, and extreme environments
- Strong, tough, and resistant to fatigue and thermal-fatigue
- Widely used in high-performance aerospace, power generation, and marine applications
- Excellent weldability and formability for complex shapes and components

Specifications

Nickel Sheet
Thickness 0.3mm - 6.0mm
Width 1000mm - 2200mm
Length Produce as requirement
Nickel Plate
Thickness 3.0mm - 300mm
Width 1000mm - 3000mm
Length Produce as requirement
Nickel Strip / Nickel Foil
Thickness 0.02mm - 16.0mm
Width 5mm - 900mm
Nickel Coil
Thickness 0.3mm - 16.0mm
Width 1000mm - 3000mm
Nickel Pipe
Outside Diameter 6.0mm - 1219mm
Thickness 0.5mm - 100mm
Nickel Capillary Pipe
Outside Diameter 0.5mm - 6.0mm
Thickness 0.05mm - 2.0mm
Nickel Bar
Diameter Ф4mm - Ф600mm
Nickel Wire Rod
Diameter Ф0.01mm - Ф6.0mm


Chemical Component

Inconel Alloy

Item
600
601
617
625
690
718
X750
825
C
≤0.15
≤0.1
0.05-0.15
≤0.1
≤0.05
≤0.08
≤0.08
≤0.05
Mn
≤1
≤1.5
≤0.5
≤0.5
≤0.5
≤0.35
≤1
≤1
Fe
6-10
rest
≤3
rest
7-11
rest
5-9
≥22
P
≤0.015
≤0.02
≤0.015
--
--
--
--
--
S
≤0.015
≤0.015
≤0.015
≤0.015
≤0.015
≤0.01
≤0.01
≤0.03
Si
≤0.5
≤0.5
≤0.5
≤0.5
≤0.5
≤0.35
≤0.5
≤0.5
Cu
≤0.5
≤1
--
≤0.3
≤0.5
≤0.3
≤0.5
1.5-3
Ni
≥72
58-63
≥44.5
50-55
≥58
50-55
≥70
38-46
Co
--
--
10-15
≤10
--
≤1
≤1
--
Al
--
1-1.7
0.8-1.5
≤0.8
--
0.2-0.8
0.4-1
≤0.2
Ti
--
--
≤0.6
≤1.15
--
--
2.25-2.75
0.6-1.2
Cr
14-17
21-25
20-24
17-21
27-31
17-21
14-17
19.5-23.5
Nb+Ta
--
--
--
4.75-5.5
--
4.75-5.5
0.7-1.2
--
Mo
--
--
8-10
2.8-3.3
--
2.8-3.3
--
2.5-3.5
B
--
--
≤0.006
--
--
--
--
--


Incoloy Alloy

Grade
800
800H
800HT
825
 925
Chemical
Composition
(%)
C
 ≤0.1 0.05-0.1 0.06-0.1 ≤0.05 ≤0.03
Mn ≤1.5 ≤1.5 ≤1.5 ≤1 ≤1
Fe rest rest rest rest rest
P
 -- -- -- ≤0.02 ≤0.03
S
 ≤0.015 ≤0.015 ≤0.015 ≤0.03 ≤0.03
Si
 ≤1 ≤1 ≤1 ≤0.5 ≤0.5
Cu
 ≤0.75 ≤0.75 ≤0.75 1.5-3 1.5-3
Ni
 30-35 30-35 30-35 38-46 42-46
Al
 0.15-0.6 0.15-0.6 0.15-0.6 0.2-1 0.15-0.5
Ti
 0.15-0.6 0.15-0.6 0.15-0.6 0.6-1.2 1.9-2.4
Cr 19-23 19-23 19-23 19.5-23.5 19.5-23.5
Mo -- -- -- 2.5-3.5 2.5-3.5


Hastelloy Alloy

Grade
C276
C22
C4
B2
 B3 N
Chemical
Composition
(%)
C
≤0.01
≤0.015
≤0.015
≤0.02
 ≤0.01 0.04-0.08
Mn
 ≤1 ≤0.5 ≤1 ≤1 ≤3 ≤1
Fe
 4-7 2-6 ≤3 ≤2 ≤1.5 ≤5
P
 ≤0.04 ≤0.02 ≤0.04 ≤0.04 -- ≤0.015
S
 ≤0.03 ≤0.02 ≤0.03 ≤0.03 -- ≤0.02
Si
 ≤0.08 ≤0.08 ≤0.08 ≤0.1 ≤0.1 ≤1
Ni
 rest rest rest rest ≥65 rest
Co
 ≤2.5 ≤2.5 ≤2 ≤1 ≤3 ≤0.2
Ti+Cu
 -- -- ≤0.7 -- ≤0.4 ≤0.35
Al+Ti
 -- -- -- -- ≤0.5 ≤0.5
Cr 14.5-16.5 20-22.5 14-18 ≤1 ≤1.5 6-8
Mo 15-17 12.5-14.5 14-17 26-30 ≤28.5 15-18
B -- -- -- -- -- ≤0.01
W 3-4.5 2.5-3.5 -- -- ≤3 ≤0.5
V ≤0.35 ≤0.35 -- 0.2-0.4 -- ≤0.5
Main Products
Inconel
Inconel 722, Inconel 725, Inconel X-750, Inconel 625, Inconel 686, Inconel 690, Inconel 702, Inconel 706, Inconel 713C, Inconel 600, Inconel 601, Inconel 602CA, Inconel 617, Inconel 718.
Incoloy Incoloy 945, Incoloy A-286, Incoloy 901, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy 926, Incoloy 330, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 801, Incoloy 840, Incoloy 20, Incoloy 205, Incoloy 208
Hastelloy Hastelloy C 276, Hastelloy G, Hastelloy W, Hastelloy X, Hastelloy G-30, Hastelloy G-35, Hastelloy G3, Hastelloy N, Hastelloy S, B-2, Hastelloy B-3, Hastelloy C2000, Hastelloy C22
Haynes Haynes 75, Haynes 244, Haynes 25, Haynes 263, Haynes 282, Haynes 556, Haynes 188, Haynes 230, Haynes 233, Haynes 242
Monel Monel 400, Monel K-500, Monel R405, Monel 401, Monel 404, Monel 405.
Nimonic Nimonic 91, Nimonic C263, Nimonic PE11, Nimonic PE16, Nimonic PK33, Nimonic 80A, Nimonic 96, Nimonic 90, Nimonic 901, Nimonic 105, Nimonic 115
Other Nickel Waspaloy, Multimet N155, Mumetal 80, Rene 41, Kovar, Maraging 250, Maraging 300, Maraging 350, MP159, MP35N, Alloy 46, Alloy 48, Alloy 52, Alloy 42, Alloy 45, Cobalt alloy 6b, Custom 455, Invar 36, Invar 42, Nickel 200, Nickel 201

Nickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 SheetNickle Chrome Nickel Alloy Inconel 625 UNS N06625 Sheet Inconel Alloy 625 Sheet

FAQ

Q1: What is your terms of payment?
A: 30% T/T in advance, the balance 70% before delivery. We will show you the photos of products and package before you pay the balance.

Q2: what is the terms of delivery?
A: EXW, FOB, CIF, CFR, DDU

Q3: What is the terms of packing?
A: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.

Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your deposit. For production period,it usually takes about 15 days-30 days after receiving the deposit.

Q5: Could you provide the samples?
A: yes, we could provide the free samples on conditons it is available in stocks, however, the the transportation fee is borne by buyer.

Q6: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Lenser piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
