304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
Specifications
MOQ :
30
Price :
2.01
Shape :
U Channel
Technique :
Hot Rolled
Surface Treatment :
Bright
Grade :
201 304 310S 316L 321 2205
Angle Bar Size :
30*30*3 - 200*200*10mm * 6m length
Channel Bar Size :
50*30*3 - 200*100*10mm * 6m length
Angle Bar Thickness :
3-10mm
Channel Bar Thickness :
3-12mm
Angle Bar Weight :
0.894-15.0 kg/m
Channel Bar Weight :
1.79-35.8 kg/m
Standard :
ASTM GB DIN
Length :
6m
Material :
304 Stainless Steel
Service :
Cutting
Packing :
Waterproof paper or wooden pallets
Description
304 Stainless Steel Channels & Angle Bars
High-quality stainless steel U channels and angle bars available at competitive prices with immediate stock availability.
Product Specifications
Product NameStainless Steel Angle Bar / Stainless Steel Channel Bar
Grade201, 304, 310S, 316L, 321, 2205, etc.
StandardASTM, GB, DIN
Size of Angle Bar30×30×3 - 200×200×10mm × 6m length
Size of Channel Bar50×30×3 - 200×100×10mm × 6m length
ServiceCutting
PackingWaterproof paper surround or wooden pallets
BrandTSINGSHAN
Stainless Steel Angle Bar Specifications
Size (A×B mm)Thickness (mm) / Weight per meter (kg)
345678910
20×200.8941.131.38
25×251.131.451.772.06
30×301.371.772.172.53
35×351.612.092.573.01
40×401.852.412.973.49
45×452.122.763.404.00
50×502.363.073.794.465.135.766.427.06
60×604.585.426.247.03
63×635.035.956.847.718.609.48
70×705.426.427.398.349.3110.3
75×755.826.897.958.9710.011.1
80×807.378.509.6110.711.8
90×908.339.6511.9012.213.4
100×1009.2810.812.2013.615.0
Stainless Steel Channel Bar Specifications
Size (H×B mm)Thickness (mm) / Weight per meter (kg)
34567891012
40×201.79
50×252.27
60×302.743.564.375.12
70×353.234.215.176.08
80×403.714.845.967.03
90×454.255.556.838.05
100×504.736.187.628.9810.311.713.041.2
120×609.2010.912.614.2
130×6510.111.913.815.517.319.1
140×7012.914.916.818.820.7
150×7513.916.018.120.222.226.3
160×8014.817.119.321.623.828.1
180×9016.719.422.024.527.032.0
200×10018.621.624.527.430.235.8
About Our Company
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
Our company specializes in stainless steel material wholesale, processing, storage, and distribution as a comprehensive stainless steel industry and trade enterprise. Located in Wuxi, the stainless steel trading center, with a total investment of 10 million yuan and annual sales exceeding 300 million yuan.
Manufacturing Partnerships
We maintain long-term, stable cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute stainless steel plates imported from Sweden, North America, South Africa, Japan, South Korea, and other regions.
Material Range
  • 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L
  • High-temperature resistant stainless steel series
  • Duplex stainless steel series
  • Super stainless steel series and other specialized materials
Processing Capabilities
  • Plasma cutting machines
  • Coil material opening equipment
  • Laser cutting machines
  • 8K mirror, grinding, wire drawing, film and titanium plating equipment
  • Material opening, strip cutting, plate cutting
  • Oil mill wire drawing, complete coil oil film wire drawing
  • 8K mirror finishing, titanium plating processing
Specialized Services
Thick plate complete plate zero cutting, circular cutting, square cutting, shaped cutting, casting parts, forging parts. Product thickness up to 150MM. All special materials and specifications can be customized to steel mill requirements according to customer specifications.
Our materials are widely used in machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment, and other industrial sectors.
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
Product Gallery
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
Applications
304 Stainless Steel U Channel Hot Rolled with Bright Surface for Structural Applications
Stainless steel angle bars and channel bars are primarily used for frame structures including:
  • High-voltage power transmission towers
  • Frame structures on both sides of main beams in steel structure bridges
  • Columns and booms of tower cranes on construction sites
  • Columns and beams in workshop structures
  • Air-conditioning and solar-powered shelf supports under windows
Widely applied in building structures and engineering construction such as house beams, ship beams, industrial furnaces, and various industrial applications across multiple sectors.
