Specifications
MOQ :
30
Price :
1.88
Shape :
U Channel
Technique :
Hot Rolled
Surface Treatment :
Bright
Specification :
30*30-100*100
Grade :
201 304 310S 316L 321 2205
Angle Bar Size :
30*30*3 - 200*200*10mm * 6m length
Channel Bar Size :
50*30*3 - 200*100*10mm * 6m length
Angle Bar Thickness :
3-10mm
Channel Bar Thickness :
3-12mm
Angle Bar Weight :
0.894-15.0 kg/m
Channel Bar Weight :
1.79-35.8 kg/m
Service :
Cutting
Packing :
waterproof paper surround or wooden pallets
Material :
Stainless Steel
Length :
6m
Description
310S ASTM A276 Pickled Polish Stainless U Channel / Stainless Steel Channels
High-quality stainless steel angle bars and channel bars manufactured to ASTM standards with pickled and polished surface finish.
Product Specifications
  • Product Name: Stainless Steel Angle Bar / Stainless Steel Channel Bar
  • Grade: 201, 304, 310S, 316L, 321, 2205, etc.
  • Standard: ASTM, GB, DIN
  • Angle Bar Size: 30×30×3 - 200×200×10mm × 6m length
  • Channel Bar Size: 50×30×3 - 200×100×10mm × 6m length
  • Service: Cutting
  • Packing: Waterproof paper surround or wooden pallets
  • Brand: TSINGSHAN
Standard Size and Weight per Meter - Stainless Steel Angle Bar
Size A×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm
20×200.8941.131.38
25×251.131.451.772.06
30×301.371.772.172.53
35×351.612.092.573.01
40×401.852.412.973.49
45×452.122.763.404.00
50×502.363.073.794.465.135.766.427.06
60×604.585.426.247.03
63×635.035.956.847.718.609.48
70×705.426.427.398.349.3110.3
75×755.826.897.958.9710.011.1
80×807.378.509.6110.711.8
90×908.339.6511.9012.213.4
100×1009.2810.812.2013.615.0
Standard Size and Weight per Meter - Stainless Steel Channel Bar
Size H×B (mm) 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm 12mm
40×201.79
50×252.27
60×302.743.564.375.12
70×353.234.215.176.08
80×403.714.845.967.03
90×454.255.556.838.05
100×504.736.187.628.9810.311.713.041.2
120×609.2010.912.614.2
130×6510.111.913.815.517.319.1
140×7012.914.916.818.820.7
150×7513.916.018.120.222.226.3
160×8014.817.119.321.623.828.1
180×9016.719.422.024.527.032.0
200×10018.621.624.527.430.235.8
About Our Company
310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications
Our company is a comprehensive stainless steel enterprise specializing in material wholesale, processing, storage, and distribution. Located in Wuxi, the stainless steel trading center, we have a total investment of 10 million yuan with annual sales exceeding 300 million yuan.
We maintain long-term, stable cooperative relationships with renowned steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and distribute imported stainless steel plates from Sweden, North America, South Africa, Japan, and South Korea.
Material Range
310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L and other materials including high-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series.
Processing Capabilities
Our facility features plasma cutting machines, coil material opening equipment, laser cutting machines, 8K mirror finishing, grinding wire drawing, film and titanium plating equipment. We offer material opening, strip cutting, plate cutting, oil mill wire drawing, full coil oil film wire drawing, 8K mirror finishing, and titanium processing.
Specialized Services
Thick plate whole plate zero cutting, cutting rounds, cutting squares, cutting shaped pieces, casting parts, forging parts with product thickness up to 150MM. All special materials and specifications can be customized to steel mill requirements according to customer specifications.
Our materials are widely used in machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment and other industries.
310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications
Product Photos
310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications 310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications
Applications
310S ASTM A276 Pickled Polish Stainless Steel U Channel Hot Rolled for Structural Applications
Stainless steel angle bars and channel bars are primarily used for frame structures including high-voltage power transmission towers, frame structures on both sides of the main beam of steel structure bridges, columns and booms of tower cranes on construction sites, and columns and beams of workshops. They are also used for air-conditioning and solar-powered shelves mounted under windows.
Widely applied in building structures and engineering construction such as house beams, ship beams, industrial furnaces, and various other applications across multiple industries.
