Specifications
Model Number :
EM-T (PV60-500VDC) EM6200T-48L
Price :
To be negotiated
Inverter Type :
hybrid solar inverter
Supply Ability :
2000 pieces per month
Charging Mode :
MPPT
Frequency :
50Hz/60Hz
Payment Terms :
L/C,T/T
Operating Temperature :
-10°C To 50°C
Output Voltage :
48VDC
MOQ :
1 piece
Delivery Time :
30 days
Size :
438*312*122mm
Place of Origin :
China
Packaging Details :
carton box
Certification :
CE, IEC
Brand Name :
1stess
Description
High-Power Single Phase Pure Sine Wave Solar Inverter
6200W 48V MPPT 120A dual output off-grid home power solution with advanced solar charging capabilities
Key Features & Benefits
  • High-power single-phase output - 6200VA/6200W capacity suitable for residential and light commercial applications
  • Dual independent outputs - Separate power channels for personal computers (10ms transfer) and home appliances (20ms transfer)
  • Advanced MPPT solar charging - 60-500 VDC operating range with 500 VDC maximum open-circuit voltage
  • High-efficiency charging - Solar charge up to 120A, AC charge up to 80A, combined maximum 120A
  • Lithium battery ready - Supports lithium battery activation via PV or utility with RS485 BMS communication
  • Pure sine wave output - Safe operation for sensitive electronics and motor-driven appliances
  • Peak efficiency 94% - Minimizes energy loss and maximizes power delivery
Technical Specifications
Feature Specification
Model EM6200T-48L
Phase Configuration 1-phase in / 1-phase out
Rated Output Voltage 220/230 VAC ±5%
Frequency 50/60 Hz auto-sensing
Battery Voltage 48 VDC
Float Charge Voltage 54 VDC
Overcharge Protection 63 VDC
Charging Method CC/CV (Constant Current/Constant Voltage)
Solar Charger Type MPPT (Maximum Power Point Tracking)
Max PV Input Power 6500 W
Max PV Open-Circuit Voltage 500 VDC
Max Solar Input Current 27 A
Max Solar Charge Current 120 A
Max AC Charge Current 80 A
Communication Ports RS485 (RJ45) / RS232 (DB9)
Operating Temperature -10°C to +50°C
Humidity 5% - 95% RH (non-condensing)
Dimensions (D x W x H) 438 x 312 x 122 mm
Advanced System Features
  • MPPT solar charge management - Continuously tracks maximum power point for optimal energy harvest
  • Intelligent dual-output distribution - Custom transfer times based on load type requirements
  • Lithium battery activation & communication - Wakes dormant batteries and exchanges BMS data
  • Overload protection - Automatic shutdown after 5s @ ≥140% load or 10s @ 100-140% load
  • Wide-voltage adaptability - 170-280 VAC (PC mode) or 90-280 VAC (home appliance mode)
  • Battery-free operation - Capable of running directly from solar PV without battery
  • Environmental protection - Detachable dust cover for harsh environments
  • Remote monitoring - Optional WiFi for real-time system monitoring
  • Multiple output priorities - UTL, SOL, SBU, SUB modes for flexible power management
  • Battery optimization - EQ function extends battery lifecycle and performance
Product Images
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Single Phase Pure Sine Wave Solar Inverter 6200W 48V MPPT 120A Dual Output Off Grid Home
Regional Application FAQs
Philippines Applications
Is the EM6200T-48L suitable for areas in the Philippines with frequent typhoons and power outages?
Absolutely. Its 10ms transfer time ensures critical devices like computers and medical equipment experience near-uninterrupted power. The robust build and detachable dust cover offer extra protection against harsh, humid environments common during typhoon seasons.
Can I use this inverter with a generator during long-term brownouts?
Yes. The inverter seamlessly accepts AC input from generators within its voltage range (90-280VAC), making it an ideal backbone for a reliable home energy system during extended outages.
We have strong sun but also sudden rain. How does the MPPT handle changing weather?
The advanced 120A MPPT charger continuously tracks the Maximum Power Point, optimizing solar energy harvest even during rapidly fluctuating conditions—from full sun to partial clouds—ensuring you get the most power possible every day.
Vietnam Applications
The voltage in rural Vietnam can be unstable. Can this inverter handle it?
Yes. It accepts a very wide AC input voltage range (90-280VAC), specifically designed to handle the unstable grid voltage common in rural and industrial areas, protecting your appliances.
Can I use this for a small workshop or farm?
Certainly. The dual output feature allows for smart load management. You can prioritize essential workshop machinery on the main output and use the second output for less critical loads, optimizing your power usage.
Is the Wi-Fi monitoring module easy to install and use?
Yes, the optional Wi-Fi module is plug-and-play. You can easily monitor your system's performance, energy savings, and status in real-time from your smartphone, which is perfect for tech-savvy users in Vietnam.
Indonesia Applications
Is this inverter a good solution for my off-grid home in a remote Indonesian island?
Perfectly. It can run without a battery using only solar power and has a massive 120A solar charge controller, making it the heart of a reliable, independent power system for island living.
Can it withstand the hot and humid coastal environment?
Yes. Its anti-corrosion components and detachable dust cover protect against salty, humid air. The operating temperature range of -10°C to 50°C is more than sufficient for the Indonesian climate.
How does the dual output benefit a typical Indonesian household?
You can set one output for critical, always-on loads (like a refrigerator and lights) and the other for non-essential loads (like a water heater), which can be automatically shed when solar power is low, ensuring smart energy management.
