Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Specifications
Model Number :
EM (PV60-500VDC) 620048L
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Operating Temperature :
-10°C To 50°C
Output Voltage :
48VDC
Price :
To be negotiated
Inverter Type :
hybrid solar inverter
Supply Ability :
2000 pieces per month
Charging Mode :
MPPT
Frequency :
50Hz/60Hz
MOQ :
1 piece
Delivery Time :
30 days
Size :
438*295*105mm
Place of Origin :
China
Packaging Details :
carton box
Certification :
CE, IEC
Brand Name :
1stess
Description
Smart Off-Grid Inverter with Advanced Energy Management
Lithium Battery Activation via PV or Utility - Wakes up deeply discharged Li-ion batteries, preventing premature disposal.
Operates Without a Battery - Works grid-connected or directly from PV, lowering initial costs for budget-conscious off-grid installations.
Pure Sine Wave Output - Clean power for all loads (inductive/capacitive), including air conditioners, refrigerators, and motors.
Power Factor 1.0 - Delivers full rated power without derating, maximizing real load capacity.
Wide PV Input Range - 60Vdc - 500Vdc MPPT voltage, compatible with various solar panel configurations.
High-Current Built-in MPPT - Solar charge current up to 60A - 120A, with PV-to-inverter efficiency up to 96%.
Multiple Output Priority Modes - UTL, SOL, SBU, SUB - Flexible energy management for different usage scenarios.
Battery Equalisation (EQ) - Optimises battery bank performance and extends cycle life.
Detachable Dust Cover - Easy cleaning, ideal for harsh/dusty environments.
Optional WiFi Remote Monitoring - Real-time system status via smartphone or PC.
Key Technical Features
LiFePO₄ Communication via RS485 - Intelligent BMS interaction for safe and efficient charging/discharging.
Dual-Source Charging - PV + AC grid can deliver total charge current up to 60A - 120A (model dependent).
Wide AC Input Range - 90-280Vac, with selectable modes for personal computers (170-280V) or home appliances (90-280V).
Fast Transfer Time - 10ms (PC mode) or 20ms (appliance mode) between grid and battery.
Overload Protection - 10s at 110-140% load, 5s at ≥140% load.
Wide Operating Temperature - -10°C to +50°C, with 5-95% non-condensing humidity tolerance.
Built-in CC/CV Charging - 3-stage intelligent charge algorithm for both lead-acid and lithium batteries.
Main Functions
Automatic energy dispatch among PV, utility, and battery
Supports lead-acid and LiFePO₄ battery types
Solar charger + AC charger integrated; priority and current limits configurable
Surge power up to 2× rated power (e.g., 6.2kW model provides 12.4kVA surge)
Dual communication ports: RS232 + RS485 for monitoring and external control
Product Specifications
Specification Model 1 Model 2 Model 3
Place of Origin China China China
Mounting Method Wall Bracket Wall Bracket Wall Bracket
Nominal Battery Voltage (V) 24VDC 48VDC 48VDC
Lithium Battery activation YES (By PV or Utility) YES (By PV or Utility) YES (By PV or Utility)
Nominal Voltage 230VAC 230VAC 230VAC
Lithium Battery communication YES (RS485) YES (RS485) YES (RS485)
Frequency 50/60Hz 50/60Hz 50/60Hz
Waveform Pure Sine wave Pure Sine wave Pure Sine wave
Solar Charger Type MPPT MPPT MPPT
Communication Interface RS232+RS485 RS232+RS485 RS232+RS485
PV Array MPPT Voltage Range 60VDC~500VDC 60VDC~500VDC 60VDC~500VDC
Surge Power 7000VA 11000VA 1240VA
Size 358*295*100mm 438*295*105mm 438*295*105mm
Weight 7kg 9kg 9kg
Operating Temperature Range -10℃ to 50℃ -10℃ to 50℃ -10℃ to 50℃
Product Images
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Internal Components View
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Connection Panel
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Side View
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Display Interface
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Installation Diagram
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Technical Specifications
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Wiring Schematic
Smart off-grid inverter, 4 output priorities, EQ, longer life, detachable dust cover
Application Examples
