High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
Specifications
Model Number :
EM-T (PV60-500VDC) EM6200T-48L
Payment Terms :
L/C,T/T
Operating Temperature :
-10°C To 50°C
Output Voltage :
48VDC
Price :
To be negotiated
Inverter Type :
hybrid solar inverter
Supply Ability :
2000 pieces per month
Charging Mode :
MPPT
Frequency :
50Hz/60Hz
MOQ :
1 piece
Delivery Time :
30 days
Size :
438*312*122mm
Place of Origin :
China
Packaging Details :
carton box
Certification :
CE, IEC
Brand Name :
1stess
Description
High Power Single Phase Inverter 6.2kW
Advanced 6200VA/6200W single-phase inverter with 94% peak efficiency, designed for residential and light commercial off-grid applications. Features 500V MPPT technology and 120A charging capability.
Key Features & Benefits
  • High-Power Output: 6200VA/6200W capacity suitable for residential and light commercial use
  • Dual Independent Outputs: Separate power distribution for personal computers (10ms transfer) and home appliances (20ms transfer)
  • Advanced MPPT Technology: 60-500 VDC operating range with 500 VDC maximum open-circuit voltage
  • Rapid Charging Capability: Solar charge up to 120A, AC charge up to 80A, combined maximum 120A
  • Lithium Battery Ready: Supports lithium battery activation via PV or utility with RS485 BMS communication
  • Wide Voltage Tolerance: Accepts 90-280 VAC input for unstable grid conditions
  • Pure Sine Wave Output: Safe operation for sensitive electronics and motor-driven appliances
  • High Efficiency: 94% peak efficiency minimizes energy loss
Technical Specifications
Feature Specification
Phase Configuration 1-phase in / 1-phase out
Rated Output Voltage 220/230 VAC ±5%
Frequency 50/60 Hz auto-sensing
Battery Voltage 48 VDC
Float Charge Voltage 54 VDC
Overcharge Protection 63 VDC
Charging Method CC/CV (Constant Current/Constant Voltage)
Solar Charger Type MPPT (Maximum Power Point Tracking)
Max PV Input Power 6500 W
Max PV Open-Circuit Voltage 500 VDC
Max Solar Input Current 27 A
Max Solar Charge Current 120 A
Max AC Charge Current 80 A
Communication Ports RS485 (RJ45) / RS232 (DB9)
Operating Temperature -10°C to +50°C
Humidity 5% - 95% RH (non-condensing)
Dimensions (D x W x H) 438 x 312 x 122 mm
Advanced Protection & Control Features
  • MPPT Solar Charge Management: Optimizes energy harvest from PV panels
  • Intelligent Dual-Output Distribution: Custom transfer times based on load type
  • Lithium Battery Activation: Wakes dormant Li-batteries and communicates with BMS
  • Overload Protection: Automatic shutdown at 140% load (5s) or 100-140% load (10s)
  • Wide Voltage Adaptability: 170-280 VAC (PC mode) or 90-280 VAC (appliance mode)
Model: EM6200T-48L
Additional Features: Dual output smart load management, battery-less operation capability, detachable dust cover, optional WiFi remote monitoring, multiple output priority support (UTL, SOL, SBU, SUB), EQ function for battery optimization
Product Images
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
High Power Single Phase Inverter 6.2kW 94% Efficiency 500V MPPT 120A Charging Off Grid
