High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
Specifications
Model Number :
QH series
Paper board :
210-700gsm And B/E/F Flute
Certification :
CE
Max Line Speed :
400m/min
Brand Name :
ZHANTIAN
Function :
Side gluing/Prefolding/Lock bottom/ 4/6 corner
Place of Origin :
CHINA
Size :
650/850/1100
Description
ZH-QH Super Speed 4/6 Corner Box Folding Gluing Machine
Product Overview

High-Performance Linear Modular Folder Gluer

Engineered for versatility and precision, this folder gluer features a linear modular design that allows for seamless future upgrades. The ultra-long conveyor ensures superior bonding strength, while the independent electrical cabinet provides enhanced anti-interference capabilities for stable, high-speed operations.

  • Linear Modularity: Easily combined and upgraded for evolving production needs
  • Enhanced Bonding: Ultra-long conveyor system for firmer box sealing
  • Stable Performance: Independent electrical case for superior anti-interference
Product Attributes
Customization Supported
MOQ 1 set
Packaging 5 packages
Delivery Time 30 days
Technical Specifications
Parameter Specification
Function Single/Double side gluing, lock bottom, 4/6 corner
Paper Board 210-800 g/m², N/E/F corrugated box
Speed 0-400 m/min
Power 27KW 380V 3P
Weight 6500KG
Loading Port NINGBO PORT, CHINA
Payment TT/ LC/ Western Union
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
High-Speed Linear Modular Box Folding Gluing Machine with 4/6 Corner Function for Corrugated Boxes
Frequently Asked Questions
What is the machine warranty?
One year.
Does your machine have CE certificate?
Yes, issued by Italian organization.
What is the production time while placing order?
About 20-25 days.
What is the delivery time?
15-30 days after receiving payment.
Can your company handle shipping for customers?
Yes, just provide us with destination sea port or container yard.
Is the packing strong?
Yes, all packages are double-checked before delivery.
How about after-sales service process?
We offer lifetime after-sales service. Please feel free to contact our after-sales department.
Are you manufacturer or trading company?
We are manufacturer.
Do you have machines in stock?
For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.
Do you inspect machines before packing?
Of course we do. We have QC department to debug the machine before packing.
What's the payment term?
T/T 30% in advance, the balance paid before delivery. We also accept payment via West Union and L/C.
Do you accept factory visiting?
We highly welcome your visit.
